Service Caster

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product Name, Brand, Label, Publisher, StudioService Caster
Attribute00, NumberOfItems, Number_of_items4
Attribute012
Attribute02, Material, MaterialTypeGlass Filled Nylon
Attribute03Top Plate
Attribute04Bright Zinc Plated Finish
Attribute05, Model, ModelNumber, Model_numberSeries#KP30
Attribute063200
Attribute07-45 degrees F to 190 degrees F
Attribute082-5/8" x 3-5/8" to 3" x 3"
Attribute094 Bolt on Swivel Locks & 2 Top Lock Brakes
Attribute1085D
Attribute114" x 4-1/2"
Attribute12(2) Swivel caster w/side lock brake & bolt on swivel lock & (2) swivel casters w/bolt on swivel locks
Attribute135-5/8"
Attribute14, countryOfOriginUnited States
AttributeKey00, length_AttribWheel Dia.
AttributeKey01, width_AttribWheel Width
AttributeKey02Material
AttributeKey03Caster Mounting Type
AttributeKey04Finish
AttributeKey05Series
AttributeKey06Capacity (Lb.)
AttributeKey07Caster Temp. Range
AttributeKey08Plate Caster Bolt Hole Pattern
AttributeKey09Caster Swivel Lock Type
AttributeKey10Durometer
AttributeKey11Plate Size
AttributeKey12Type
AttributeKey13, height_AttribMounting Height
AttributeKey14Country of Origin (subject to change)
DimensionUnitinch
WeightUnitlbs
diameter, length4.0
extendedLead26
extendedQty-2
height5.625
jsonUrlData924526ffbdad25e5923b
moq, multiple, tierMinQty1, Item_package_quantity, PackageQuantity1
MPN, PartNumber, Part_numberSCC-KP30S420-GFNR-SLB-BSL-2-BSL-2
qtyInStock0
tierPrice1679.6
urlhttps://www.zoro.com/service-caster-4-inch-kingpinless-glass-filled-nylon-wheel-caster-swivel-locks-2-brakes-4pk-scc-kp30s420-gfnr-slb-bsl-2-bsl-2/i/G605436560/
width2.0
ASINB08K1J2P9B B08KHG3DXF
AdultProduct, Autographed, Batteries_required, Memorabilia, TradeInEligibleFalse
Amount0.00
AsinB08K1J2P9B
Bullet_pointBrake options include a side lock brake (SLB) which applies a positive locking force against the wheel hub which prevents the wheel from moving freely, or a bolt-on swivel lock (BSL) that when inserted into one of 4 notches found on the swivel raceway converts a swivel caster to rigid for straight-line tracking at any 90 degree angle. Combining both brake types ensures complete immobility over both swivel and wheel on the caster. Find other wheel materials, sizes and all Service Caster products at our Amazon Storefront. Click on the “by Service Caster” link above the main title on any Service Caster page listing. These Service Caster Series #KP30 Glass Filled Nylon casters offer various wheel sizes and mounting heights: 4” Wheel: 5-5/8” mounting height; 5” wheel: 6-1/2” mounting height; 6” wheel: 7-1/2” mounting height; 8" wheel: 9-1/2" mounting height. Top plate measures at 4" x 4-1/2" with a bolt hole pattern of 2-5/8" x 3-5/8" to 3" x 3" and can either be bolted or welded on. Weight capacity ranges from 1200 lbs on the 4” caster, 1000 lbs on the 5”, 1200 lbs on the 6” and 1250 lbs. on the 8”.
ClassificationId511228
Color4 Swivel w/2 Brakes & 4 Swivel Locks
Currency, CurrencyCodeUSD
DisplayNameHardware
FetchTime1698957523 1704535787
Height, Width1000 500 75
ItemClassificationBASE_PRODUCT
ItemName, Item_name, TitleKingpinless Glass Filled Nylon Swivel Top Plate Caster Set 4 w/4" x 2" Black Wheels-Includes 2 Swvl w/Brakes and Bolt on Swvl Lcks& 2 Swvl w/Bolt on Swvl Lcks-4800 lbs Total Cpty- Service Caster Brand
Item_type_keywordplate-casters
KeywordSCC-KP30S420-GFNR-BSL-2-R-2
Linkhttps://m.media-amazon.com/images/I/319ZGs7JqYL._SL75_.jpg https://m.media-amazon.com/images/I/319ZGs7JqYL.jpg https://m.media-amazon.com/images/I/41Ht73Lp5TL._SL75_.jpg https://m.media-amazon.com/images/I/41Ht73Lp5TL.jpg https://m.media-amazon.com/images/I/51C+HAQhaxL.jpg https://m.media-amazon.com/images/I/51Hegn-qeJL.jpg https://m.media-amazon.com/images/I/51k3QxdGldL._SL75_.jpg https://m.media-amazon.com/images/I/51k3QxdGldL.jpg https://m.media-amazon.com/images/I/51qAAKqgHoL._SL75_.jpg https://m.media-amazon.com/images/I/51qAAKqgHoL.jpg https://m.media-amazon.com/images/I/51sbq2ARStL._SL75_.jpg https://m.media-amazon.com/images/I/51sbq2ARStL.jpg https://m.media-amazon.com/images/I/51zL-ecbp+L._SL75_.jpg https://m.media-amazon.com/images/I/51zL-ecbp+L.jpg https://m.media-amazon.com/images/I/61PP01j6zlL.jpg https://m.media-amazon.com/images/I/61sX0Wm+5CL.jpg https://m.media-amazon.com/images/I/61xuoomYo4L.jpg https://m.media-amazon.com/images/I/71fgQlKw78L.jpg
List_price0.0
Load_capacity800.0
Marketplace_idATVPDKIKX0DER
Name, ThemeSIZE_NAME/COLOR_NAME
ParentAsinsB08KHG3DXF
ProductGroup, WebsiteDisplayGroupNameBISS Basic
ProductType, ProductTypeNameWHEEL
Product_descriptionListing is for a set of four (4) Service Caster Series #KP30 casters, two (2) swivel casters with side lock brakes & bolt on swivel locks and two (2) swivel casters with a bolt on swivel locks, with 4" diameter by 2" wide glass filled nylon wheels capable of supporting a total weight of 3,200 lbs. (1200 lbs./caster). When searching for a reliable and durable solution to your caster needs, consider Service Caster Series KP30 glass filled nylon casters. The Service Caster Series KP30 is ideal for medium and heavy duty material handling, carts, equipment, and shop projects. The zinc plated finish provides durability under any condition and the glass filled nylon wheels provide very low rolling resistance, will not flat spot, are resistant to most chemical and oils, and under normal operating conditions are maintenance free. Featuring a Kingpinless hot forged ASTM1045 steel design that increases caster durability and integrity, the series KP30 eliminates problems associated with kingpin failure due to severe shock loading. In addition, the Kingpinless design features 3/8” diameter HRC45 steel ball bearings which absorb thrust and load in severe environments. Lastly, Service Caster’s Series KP30 casters are finely crafted with grease fittings, and 4 position notches to accept 4-position locks. These highly versatile casters are ideal for a wide range of applications, such as dollies, platform trucks, warehouse carts and freight terminals. Even drywall carts, welding carts, and wall panel carts will be ready to roll on the Series KP30, keeping you moving forward.
Product_site_launch_date2020-09-24T19:59:35.618Z
Size4" Wheel
Supplier_declared_dg_hz_regulationnot_applicable
TypeVARIATION
URLhttps://m.media-amazon.com/images/I/319ZGs7JqYL._SL75_.jpg
Unitpounds
Unitspixels
VariantMAIN PT01 PT02 PT03 PT04 PT05
VariationThemecolor size
WebsiteDisplayGroupbiss_basic_display_on_website
Website_shipping_weight24.1

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG605436560111 @ $679.60

Related on Amazon

As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.

Kingpinless Glass Filled Nylon Swivel Top Plate Caster Set 4 w/4" x 2" Black Wheels-Includes 2 Swvl w/Brakes and Bolt on Swvl Lcks& 2 Swvl w/Bolt on Swvl Lcks-4800 lbs Total Cpty- Service Caster Brand
Brand: Service Caster
Listing is for a set of four (4) Service Caster Series #KP30 casters, two (2) swivel casters with side lock brakes & bolt on swivel locks and two (2) swivel casters with a bolt on swivel locks, with 4" diameter by 2" wide glass filled nylon wheels capable of supporting a total weight of 3,200 lbs. (1200 lbs./caster). When searching for a reliable and durable solution to your caster needs, consider Service Caster Series KP30 glass filled nylon casters. The Service Caster Series KP30 is ideal for medium and heavy duty material handling, carts, equipment, and shop projects. The zinc plated finish provides durability under any condition and the glass filled nylon wheels provide very low rolling resistance, will not flat spot, are resistant to most chemical and oils, and under normal operating conditions are maintenance free. Featuring a Kingpinless hot forged ASTM1045 steel design that increases caster durability and integrity, the series KP30 eliminates problems associated with kingpin failure due to severe shock loading. In addition, the Kingpinless design features 3/8” diameter HRC45 steel ball bearings which absorb thrust and load in severe environments. Lastly, Service Caster’s Series KP30 casters are finely crafted with grease fittings, and 4 position notches to accept 4-position locks. These highly versatile casters are ideal for a wide range of applications, such as dollies, platform trucks, warehouse carts and freight terminals. Even drywall carts, welding carts, and wall panel carts will be ready to roll on the Series KP30, keeping you moving forward.
Details
  • These Service Caster Series #KP30 Glass Filled Nylon casters offer various wheel sizes and mounting heights: 4” Wheel: 5-5/8” mounting height; 5” wheel: 6-1/2” mounting height; 6” wheel: 7-1/2” mounting height; 8" wheel: 9-1/2" mounting height.
  • Weight capacity ranges from 1200 lbs on the 4” caster, 1000 lbs on the 5”, 1200 lbs on the 6” and 1250 lbs. on the 8”.
  • Top plate measures at 4" x 4-1/2" with a bolt hole pattern of 2-5/8" x 3-5/8" to 3" x 3" and can either be bolted or welded on.
  • Brake options include a side lock brake (SLB) which applies a positive locking force against the wheel hub which prevents the wheel from moving freely, or a bolt-on swivel lock (BSL) that when inserted into one of 4 notches found on the swivel raceway converts a swivel caster to rigid for straight-line tracking at any 90 degree angle. Combining both brake types ensures complete immobility over both swivel and wheel on the caster.
  • Find other wheel materials, sizes and all Service Caster products at our Amazon Storefront. Click on the “by Service Caster” link above the main title on any Service Caster page listing.
Listing
Product groupBISS Basic
Product typeWHEEL
ModelSeries#KP30
Part numberSCC-KP30S420-GFNR-SLB-BSL-2-BSL-2
Items per pack4
LabelService Caster
ManufacturerService Caster
