6206HT200 Extra Small/Small Ball
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| MRO Supply | 830338 | 1 | 1 | 1 @ $465.27 | |
| Grainger | 13W902 | 1 | 1 | ||
| AA6GBK | 1 | 1 | 1 @ $249.35 | ||
 Misumi USA | 6206HT200 | 1 | 1 | 1 @ $215.83, 50 @ $215.83 | |
 Zoro | G3952225 | 1 | 1 | 1 @ $134.99 | |
| 6206HT200 | 1 | 1 | |||
 Radwell | 6206HT200 | 1 | 1 | ||
| Applied Industrial | 113681767 | 1 | 1 | ||
| sustainablesupply.com | C2908530 | 1 | -2 | 1 | 1 @ $148.76 |
 BDI Express | 1206532 | 1 | 1 | 1 @ $107.16 | |
| 6206HT200 | 1 | -2 | 1 | 1 @ $137.32 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
NTN Bearing 6206HT200 NTN-SNR Single Row Topline Deep Groove Radial Ball Bearing, Steel Cage, High Temperature, 30 mm Bore, 62 mm OD, 16 mm Width, Sealed
Brand: NTN Bearing
Details
- Deep groove geometry for high speeds
- Single row for supporting radial loads
- Viton contact seals protect against outside contaminants and temperature
- High Temperature range up to 400 degrees F (200 C)
- C4 radial internal clearance for radial slack between the inner and outer rings is greater than CN (normal) and C3 to compensate for thermal expansion
Listing
| Binding | Misc. |
|---|---|
| Product group | BISS Basic |
| Product type | BEARINGS_AND_BUSHINGS |
| Model | SNR 6206HT200 |
| Part number | 6206HT200 |
| Items per pack | 1 |
| Label | NTN-SNR Bearing |
| Manufacturer | NTN-SNR Bearing |
Radial Ball Bearing, Sealed Bearing Type, 30mm Bore Dia, 62mm Outside Dia.
<p> For use in high-heat applications, this high-temperature radial ball bearing offers stability at various temperatures, and is designed to adapt to operating conditions. With rust-resistant steel shields, it also helps maintain stability in the presence of water. Greases are selected to help enhance operating performance, reducing the possibility of lubricant breakdown. Cages are constructed of pressed steel for high tolerance. Use wherever you need bearings that can withstand high temperatures.</p><p><b>Specification: </b><ul><li>Item: Radial Ball Bearing</li><li>Unmounted Bearing Item: Radial Ball Bearing</li><li>Single Row/Double Row: Single Row</li><li>Seal/Shield Type: Double Sealed</li><li>Bore Dia.: 30mm</li><li>Bore Tolerance: +0/-10 micron</li><li>Outside Dia.: 62mm</li><li>Outside Dia. Tolerance: +0/-13 micron</li><li>Width: 16mm</li><li>Seal Material: Viton</li><li>Shield Material: Steel</li><li>ABEC Tolerance: 1</li><li>Dynamic Load Capacity: 4,400 lb.</li><li>Static Load Capacity: 2,550 lb.</li><li>Max. RPM: 2,900</li><li>Temp. Range: 300 Degrees to 400 Degrees F</li><li>Bearing Material: Steel</li><li>Cage Material: Steel</li><li>Lubrication: Hi Temp</li><li>Industry Number: 6206HT200</li></ul></p>
Details
- Item: Radial Ball Bearing
- Unmounted Bearing Item: Radial Ball Bearing
- Single Row/Double Row: Single Row
- Seal/Shield Type: Double Sealed
- Bore Dia.: 30mm
