Circuit breaker, PowerPacT P, 1200A, 3 pole, 600VAC, 65kA, lugs, Micrologic 5.0A, 100% | Mayer Electric

SQUARE D . SQDPKL36120CU43A

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
Attribute00circuit breaker
Attribute01PowerPact P
Attribute02PowerPact
Attribute03distribution
Attribute0418 months
Attribute05unit mount lug)
Attribute0650/60 Hz
Attribute07AL1200P25K
Attribute0825 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
Attribute09electronic, ammeter, Micrologic 5.0 A, LSI
Attribute10Micrologic 5.0 A
Attribute1116.16 in
Attribute12600 V AC 50/60 Hz UL 489
Attribute1350-50 N.m 95-240 mm? (4 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
Attribute14lug
Attribute15K
Attribute16overload 1 trip indicator green) || 1 trip indicator green) || trip causes 1 trip indicator green)
Attribute172 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Attribute18lugs line || lugs load
Attribute1932 lb(US)
Attribute208 kV IEC 60947-2
Attribute21toggle
Attribute2230 mm
Attribute231200-1200 A
Attribute24category A
Attribute250.4...1 x Ir
Attribute26100 %
Attribute27AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 50 kA 480 V AC 50/60 Hz UL 489 || AIR 50 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
Attribute28750 V IEC 60947-2
Attribute29yes IEC 60947-2
Attribute303P
Attribute31, moq, multiple, tierMinQty11
Attribute324 x AWG 3/0...500 kcmil aluminium/copper
Attribute338.27 in
Attribute348.05 in
Attribute35, Attribute36, Attribute39Yes
Attribute37ENVPEP1407012EN
Attribute38Green Premium product
Attribute40Reference contains Substances of Very High Concern above the threshold
Attribute41DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Attribute42Product out of China RoHS scope. Substance declaration for your information.
Attribute43ENVEOLI1407012EN
Attribute44Compliant
Attribute45-2-70 ?C
Attribute46UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Attribute47UL || CSA || NOM
Attribute48front cover IP40
Attribute493 IEC 60947-1
Attribute50-50-85 ?C
Attribute51CE
AttributeKey00Product Or Component Type
AttributeKey01Product Name
AttributeKey02Range
AttributeKey03Device Application
AttributeKey04Warranty
AttributeKey05Mounting Mode
AttributeKey06Network Frequency
AttributeKey07Terminal Identifier
AttributeKey08[Ics] Rated Service Breaking Capacity
AttributeKey09Trip Unit Technology
AttributeKey10Trip Unit Name
AttributeKey11, height_AttribHeight
AttributeKey12[Ue] Rated Operational Voltage
AttributeKey13Tightening Torque
AttributeKey14Mounting Support
AttributeKey15Breaking Capacity Code
AttributeKey16Local Signalling
AttributeKey17Number Of Slots
AttributeKey18Electrical Connection
AttributeKey19, Weight_AttribNet Weight
AttributeKey20[Uimp] Rated Impulse Withstand Voltage
AttributeKey21Control Type
AttributeKey22Wire Stripping Length
AttributeKey23Line Rated Current
AttributeKey24Utilisation Category
AttributeKey25Long Time Pick-Up Adjustment Range
AttributeKey26Continuous Current Rating
AttributeKey27Breaking Capacity
AttributeKey28[Ui] Rated Insulation Voltage
AttributeKey29Suitability For Isolation
AttributeKey30Poles Description
AttributeKey31Quantity Per Set
AttributeKey32Awg Gauge
AttributeKey33, width_AttribWidth
AttributeKey34, length_AttribDepth
AttributeKey35Rohs Exemption Information
AttributeKey36Mercury Free
AttributeKey37Environmental Disclosure
AttributeKey38Sustainable Offer Status
AttributeKey39Pvc Free
AttributeKey40Reach Regulation
AttributeKey41California Proposition 65 : WARNING: This product can expose you to chemicals including
AttributeKey42China Rohs Regulation
AttributeKey43Circularity Profile
AttributeKey44Eu Rohs Directive
AttributeKey45Ambient Air Temperature For Operation
AttributeKey46Standards
AttributeKey47Product Certifications
AttributeKey48Ip Degree Of Protection
AttributeKey49Pollution Degree
AttributeKey50Ambient Air Temperature For Storage
AttributeKey51Quality Labels
DimensionUnitinch
Extra Product NameCircuit breaker, PowerPacT P, 1200A, 3 pole, 600VAC, 65kA, lugs, Micrologic 5.0A, 100% | Mayer Electric
UPC, MPN, SKUSQDPKL36120CU43A
Weight32
WeightUnitlbs
depth, length8.05
height16.16
jsonUrlData/Product/SQUARE-D-Circuit-breaker-PowerPact-P-1200A-3-pole-600VAC-65kA-lugs-Micrologic-5-0A-100-SQDPKL36120CU43A
jsonUrlData22f95179b-22f0-4a56-981d-aeea00572e7d
qtyInStock0
tierPrice10.0
width8.27

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDPKL36120CU43A111 @ $0.00
