Order 3500-AL-25-NF-2 by Dwyer Smart Differential Pressure Transmitter - US Mega Store

Dwyer . 3500-AL-25-NF-2

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerDwyer
Attribute00, Attribute16Compatible gases, steam, liquids or vapors.
Attribute01, Attribute17316L SS, fluoroelastomer.
Attribute02, Attribute18±0.075% FS ( at 20°C).
Attribute03, Attribute19Up to 25:1 turn down.
Attribute04, Attribute20≤0.075%
Attribute05, Attribute21Ambient: -40 to 185°F (-40 to 85°C) ambient.
Attribute06, Attribute22< &plusmn;0.05% span/10&deg;C.
Attribute07, Attribute2310 to 55 VDC.
Attribute08, Attribute244 to 20 mA.
Attribute09, Attribute2516 to 480 ms (programmable).
Attribute10, Attribute260 to 60 seconds.
Attribute11, Attribute27Packing gland M20x1.5, two 1/2" female NPT conduit, screw terminal.
Attribute12, Attribute281/4" female or male NPT.
Attribute13, Attribute29NEMA 4X IP66/IP67.
Attribute14, Attribute30CE.
Attribute15, Attribute310 - 100 psi
AttributeKey00, AttributeKey16Service
AttributeKey01, AttributeKey17Wetted Materials
AttributeKey02, AttributeKey18Accuracy
AttributeKey03, AttributeKey19Rangeability
AttributeKey04, AttributeKey20Stability
AttributeKey05, AttributeKey21Temperature Limits
AttributeKey06, AttributeKey22Thermal Effect
AttributeKey07, AttributeKey23Power Requirements
AttributeKey08, AttributeKey24Output Signal
AttributeKey09, AttributeKey25Response Time
AttributeKey10, AttributeKey26Damping Time
AttributeKey11, AttributeKey27Electrical Connection
AttributeKey12, AttributeKey28Process Connections
AttributeKey13, AttributeKey29Enclosure Rating
AttributeKey14, AttributeKey30Agency Approvals
AttributeKey15, AttributeKey31Range
CategoryL1Process Control & Automation
CategoryL2Transmitters
CategoryL3Pressure
CategoryL4Dwyer 3500-AL-25-NF-2
Extra Product NameOrder 3500-AL-25-NF-2 by Dwyer Smart Differential Pressure Transmitter - US Mega Store
moq, multiple, tierMinQty11
MPN, SKU3500-AL-25-NF-2
qtyInStockDiscontinued
snippet<p><strong>Features: </strong> </p> <ul><li>High accuracy (&plusmn;0.075% FS) </li> <li>Rangeability (up to 25:1) </li> <li>Completely Configurable using zero/span buttons (no calibrator required) </li> <li>Fail-mode process function </li> <li>Automatic ambient temperature compensation </li> </ul> <p><strong>Applications: </strong> </p> <ul><li>Flow measurement </li> <li>Level monitoring </li> <li>Filter or pump differential pressure </li> <li>Critical process monitoring </li> </ul> <p>It is a microprocessor-based high performance transmitter, which has flexible pressure calibration, push button configuration, and is programmable using HART Communication. Capable of being configured for differential pressure or level applications with the zero and span buttons. A field calibrator is not required for configuration. The transmitter software compensates for thermal effects, improving performance. EEPROM stores configuration settings and stores sensor correction coefficients in the event of shutdowns or power loss. The rangeability allows the smart transmitter to be configured to fit any application. </p>
tierPrice11088

Distributor offers

SellerSKUMOQIn stockMultiplePrices
usmegastore.com3500-AL-25-NF-21Discontinued11 @ $1088.00
heavydutydepot.com3500-AL-25-NF-2111 @ $1088.00
Galco3500-AL-25-NF-2-DWYR111 @ $1361.14
cappusa.com4124116111 @ $0.00
globaltestsupply.com3500-AL-25-NF-212 to 3 Weeks1
us.rs-online.com71948483111 @ $1362.11
Allied Electronics7194848311
