Mini circuit breaker, E-Frame, 90A, 3 pole, 480Y/277 VAC, 25 kA max, bolt on, aux switch, alarm switch, shunt trip | Mayer Electric

SQUARE D . SQDEDB34090AABASA

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
Attribute00E-Frame
Attribute01125 A Frame EDB-EGB-EJB
Attribute022300-2300 A
Attribute03miniature circuit-breaker
Attribute04EDB
Attribute0518 months
Attribute06HACR rated
Attribute075.66 in
Attribute08bolt-on
Attribute091000 A
Attribute103.9-3.9 N.m 2.5-6 mm? (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm? (AWG 8...AWG 2/0)
Attribute11D
Attribute12NF panelboard
Attribute13lugs aluminium
Attribute14, Attribute21, Weight4
Attribute1590 A
Attribute16overload || short-circuit
Attribute17trip indicator
Attribute18AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Attribute193.92 in
Attribute204.05 in
Attribute22shunt trip || alarm switch || auxiliary switch
Attribute2318 kA 277 V AC || 25 kA 240 V AC || 18 kA 480Y/277 V AC || 25 kA 120 V AC || 25 kA 120/240 V AC
Attribute244 lb(US)
Attribute25thermal-magnetic
Attribute263
Attribute27480Y/277 V AC
Attribute28Product out of China RoHS scope. Substance declaration for your information.
Attribute29, Attribute30Yes
Attribute31Compliant
Attribute32Reference contains Substances of Very High Concern above the threshold
Attribute33cULus
Attribute3440 ?C
AttributeKey00Module Type
AttributeKey01Range Of Product
AttributeKey02Trip Unit Rating
AttributeKey03Product Or Component Type
AttributeKey04Device Short Name
AttributeKey05Warranty
AttributeKey06Circuit Breaker Application
AttributeKey07, height_AttribHeight
AttributeKey08Mounting Mode
AttributeKey09Holding Current
AttributeKey10Tightening Torque
AttributeKey11Breaking Capacity Code
AttributeKey12Product Destination
AttributeKey13Electrical Connection
AttributeKey14Number Of Spaces Required
AttributeKey15Line Rated Current
AttributeKey16Protection Type
AttributeKey17Local Signalling
AttributeKey18Awg Gauge
AttributeKey19, width_AttribWidth
AttributeKey20, length_AttribDepth
AttributeKey21Number Of Spaces
AttributeKey22Device Composition
AttributeKey23Breaking Capacity
AttributeKey24, Weight_AttribNet Weight
AttributeKey25Trip Unit Technology
AttributeKey26Number Of Poles
AttributeKey27[Ue] Rated Operational Voltage
AttributeKey28China Rohs Regulation
AttributeKey29Rohs Exemption Information
AttributeKey30Mercury Free
AttributeKey31Eu Rohs Directive
AttributeKey32Reach Regulation
AttributeKey33Product Certifications
AttributeKey34Ambient Air Temperature For Operation
DimensionUnitinch
Extra Product NameMini circuit breaker, E-Frame, 90A, 3 pole, 480Y/277 VAC, 25 kA max, bolt on, aux switch, alarm switch, shunt trip | Mayer Electric
UPC, MPN, SKUSQDEDB34090AABASA
WeightUnitlbs
depth, length4.05
height5.66
jsonUrlData/Product/SQUARE-D-Mini-circuit-breaker-E-Frame-90A-3-pole-480Y-277-VAC-25-kA-max-bolt-on-aux-switch-alarm-switch-shunt-trip-SQDEDB34090AABASA
jsonUrlData211ce488f-bda3-4539-bdea-aeea00555ae0
moq, multiple, tierMinQty11
qtyInStock0
tierPrice10.0
width3.92
