Order PAG15798B by Winters PAG Beverage & Dairy Sanitary Gauge - US Mega Store

Winters . PAG15798B

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerWinters
Attribute00, Attribute17, Attribute21, Attribute38304 SS, polished
Attribute01, Attribute02, Attribute05, Attribute22, Attribute23, Attribute260.25% of full scale
Attribute03, Attribute243/16"thick polycarbonate
Attribute04, Attribute2550% of full scale
Attribute06, Attribute27250°F (121°C) continuous
Attribute07, Attribute28300°F (149°C) 1 hour, dry
Attribute08, Attribute09, Attribute29, Attribute30316L SS, welded
Attribute10, Attribute31-22°F to 195°F (-30°C to 91°C)
Attribute11, Attribute32Less than 0.16% per 10°F (5.5°C) change in process or ambient temperature
Attribute12, Attribute33Food grade glycerin standard (Mineral oil, silicone and Neobee-20 optional)
Attribute13, Attribute34Food grade glycerin standard (Dry, mineral oil, silicone and Neobee-20 optional)
Attribute14, Attribute35Standard
Attribute15, Attribute36Externally adjustable micrometer pointer
Attribute16, Attribute37316L SS, Ra = 8 microinches
Attribute18, Attribute3940°F to 140°F (4°C to 60°C)
Attribute19, Attribute400°F to 250°F (-18°C to 121°C)
Attribute20, Attribute41+/-0.75% of full scale value
AttributeKey00, AttributeKey21Case
AttributeKey01, AttributeKey22Repeatability
AttributeKey02, AttributeKey23Linearity
AttributeKey03, AttributeKey24Lens
AttributeKey04, AttributeKey25Over-range Capability
AttributeKey05, AttributeKey26Hysteresis
AttributeKey06, AttributeKey27CIP Temperature Limit
AttributeKey07, AttributeKey28SIP Temperature Limit
AttributeKey08, AttributeKey29Bourdon Tube
AttributeKey09, AttributeKey30Socket
AttributeKey10, AttributeKey31Storage Temperature
AttributeKey11, AttributeKey32Temperature Effect
AttributeKey12, AttributeKey33Actuating Fill
AttributeKey13, AttributeKey34Case Fluid
AttributeKey14, AttributeKey35Pulsation Dampening
AttributeKey15, AttributeKey36Re-zero Feature
AttributeKey16, AttributeKey37Wetted Parts
AttributeKey17, AttributeKey38Bezel
AttributeKey18, AttributeKey39Ambient Temperature
AttributeKey19, AttributeKey40Process Temperature
AttributeKey20, AttributeKey41Accuracy
CategoryL1Process Control & Automation
CategoryL2Gauges
CategoryL3Pressure & Vacuum
CategoryL4Winters PAG15798B
ConditionNEW
Extra Product NameOrder PAG15798B by Winters PAG Beverage & Dairy Sanitary Gauge - US Mega Store
moq, multiple, tierMinQty11
MPN, SKUPAG15798B
qtyInStock-2
qtySourceFieldMap
snippet<p><strong>Winters, PAG15798B, PAG 2.5" x 1.5" 30/0/30 PSI/BAR Back Food, Beverage & Dairy Sanitary Gauge </strong> </p> <p><strong>Applications: </strong> </p> <ul><li>Built to withstand the harshest of sanitary applications and where 3A approval is required </li> </ul> <p><strong>Description & Features: </strong> </p> <ul><li>Designed for food, beverage & dairy and pharmaceutical applications </li> <li>+/-0.75% full scale accuracy </li> <li>Food grade glycerin filling standard </li> <li>Re-zero feature standard </li> <li>Crack/breakage-resistant polycarbonate lens standard </li> <li>Clean-In-Place design </li> <li>Steam-In-Place design </li> <li>Autoclavable </li> <li>ASME B40.100 compliant </li> <li>CRN registered </li> <li>5 year warranty </li> </ul>
tierPrice11310

Distributor offers

SellerSKUMOQIn stockMultiplePrices
usmegastore.comPAG15798B1-211 @ $1310.00
State SupplyWP100515 business days11 @ $801.97
heavydutydepot.comPAG15798B1-211 @ $1310.00
MegadepotPAG15798B111 @ $1310.00
RadwellPAG15798B11
