SECO-LARM . SD-996C-NUVQ

Seco-Larm SD-996C-NUVQ Electric Door Strike with Vertical Adjustment, 12/24 VDC Operation, Accommodates deadbolts up to 1", Field selectable for fail-safe or fail-secure<br><br> The SECO-LARM SD-996C-NUVQ Electric Door Strike with Vertical Adjustment is compatible with a wide range of lock types including cylindrical, mortise, and mortise exit devices and can be configured for use in wood, aluminum, or metal doors. Included are various ANSI-sized faceplates to match the door lock type. The strike is easily field-configurable for fail-safe or fail-secure applications.<br><br> Key Features<br> - 12/24 VDC Operation<br> - Vertical adjustable deadbolt opening, sliding shim keeper, and deadlatch ramp accommodates a wide range of lock types<br> - Accommodates deadbolts up to 1"<br> - Field selectable for fail-safe or fail-secure <br> - Includes 5 different stainless-steel faceplates<br> - Includes trim plate to hide gaps in installation<br> - Reversible non-handed design<br> - Static strength 1,000 lbs. (454kg)<br> - Tested to 250,000 cycles (UL Tested)<br><br> Specifications<br> - Operating Voltage: 12/24 VDC<br> - Current Draw: 300mA@12VDC, 150mA@24VDC<br> - Dynamic strength: 33 ft-lbs. (4.56 m-kgs)<br> - Latch Throw: 1” (25mm) max with 1/8” (3mm) door gap<br> - Operating Temperature: 14°F~113°F (-10°~45° C)<br> - Operating Humidity: 0~85%<br> - Dimensions: 1-13/16”x1-5/8”x3-5/16” (47x42x84 mm)<br><br>
