Seco-Larm Seco-Larm Ss-090-2H0 Tubular Key Lock Switch - High Security - SS-090-2H0

Ideal for use in residential, commercial, industrial, and vehicle burglar alarm systems, as well as computer systems, data processing equipment, and other types of equipment or machinery that requires operation by authorized personnel only. Patented "See-

Shunt ON/OFF 2 terminals, SPST. Maintained ON-OFF, key removable from both ON and OFF positions. Commonly used as ON/OFF switch to arm/disarm alarm or shunt zone. 12VDC, 2 Amps max. Minimum order of 5 pcs

The Seco-Larm Enforcer SPST Tubular Key Lock (Shunt ON/OFF) is commonly used as an ON/OFF switch to arm/disarm alarm inputs or other applications requiring high-security, maintained ON/OFF operation. It features 2 terminals and the key is removable from both ON and OFF positions. The Seco-Larm Key Lock Switches are ideal for use in residential, commercial, industrial, and vehicle burglar alarm systems, as well as computer systems, data processing equipment, and other types of equipment or machinery that requires operation by authorized personnel only. They feature patented "See-Saw" contacts to assure a reliable, automatically self-adjusted contact even after the contacts are worn out from prolonged use, or otherwise misaligned by vibration such as uneven road surfaces. They are designed and built to resist expert picking and attacking. A terminal divider between terminals prevents the possibility of shorting wires when making connections. The fiber-bakelite base is highly resistant to heat; terminals are unaffected by soldering even at 750 degrees fahrenheit (400 degrees celsius) for 120 seconds. In addition, fiber bakelite makes the base extremely durable and virtually unaffected by most forms of attack. Round terminals allow choosing between either solder or crimping connections. Key prevented from turning 360 degrees and from slipping past the ON and OFF positions. Chrome-plated brass outer housing combines durability with superior looks. Contents: Tubular Key Lock Switch, (2) Keys. Manufacturer Part Number: SS-090-2H0: (key number 1300). Voltage: 12VDC. Amperage: 2. Number of Terminals: 2. Switching Type: SPST.
