Omron Automation . EESX674A
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Master Electronics | EESX674A | 1 | 52 | 1 | 1 @ $55.81, 2 @ $37.57 |
 Newark | 18M7278 | 1 | 45 | 1 | 1 @ $37.08, 5 @ $37.08, 10 @ $37.08, 25 @ $37.08, 50 @ $37.08, 100 @ $34.43 |
| EE-SX674A | 1 | Estimated Lead Time : Usually ships in 1-10 working days. | 1 | 1 @ $12.00 | |
 TME | EE-SX674A | 1 | 5 | 1 | 1 @ $27.06, 5 @ $25.30, 10 @ $23.55 |
| Airline Hydraulics | OMRON EE-SX674A | 1 | 1 | 1 @ $37.08 | |
 Misumi USA | EE-SX674A | 1 | 1 | 1 @ $23.03, 267 @ $23.03 | |
| AC3XKP | 1 | 1 | 1 @ $68.82 | ||
| Grainger | 2XEL1 | 1 | 1 | ||
 Zoro | G1620902 | 1 | 1 | 1 @ $23.39 | |
| Waldom | OMRON ELECTRONICS EESX674A | 1 | 1 | ||
| Waldom | OMRON ELECTRONICS EE-SX674A | 1 | 1 | ||
| Allied Electronics | 70179832 | 1 | 1 | ||
| us.rs-online.com | 70179832 | 1 | 650 | 1 | 1 @ $50.90, 5 @ $49.12, 10 @ $48.10, 25 @ $47.08 |
| RS Delivers | 821-0139 | 1 | 27 | 1 | 1 @ $23.06, 5 @ $22.36, 10 @ $21.40 |
| Digi-Key | 368639 | 1 | 3305 | 1 | 1 @ $50.39, 5 @ $48.10, 10 @ $43.52, 25 @ $40.09, 50 @ $35.51, 100 @ $34.36 |
| 1Source | EE-SX674A | 1 | 1 | ||
| EESX674A | 1 | 100 | 1 | 1 @ $38.16, 10 @ $31.25, 100 @ $28.23, 1000 @ $28.23, 10000 @ $28.23 | |
| Amazon | B005T5DY4K | 1 | 1 | ||
 swatee.com | EE-SX674A | 1 | 70 | 1 | 1 @ $47.27 |
 AmazonTP | B00DKC7WUQ | 1 | 1 | 1 @ $23.19 | |
 AmazonTP | B00DECUSIK | 1 | 1 | 1 @ $29.00 | |
| Win Source | EE-SX674A | 1 | 164 | 1 | |
| Hotenda | H3940153 | 1 | 1 | 1 @ $33.65, 10 @ $29.06, 50 @ $23.71, 100 @ $22.94, 250 @ $22.18, 500 @ $21.41 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
Photoelectric Sensor, Close Mnt, Thru-Beam
Brand: Omron
'Photoelectric Sensor, Shape Close-Mounting, Sensing Method Through Beam, Operation Mode Selectable Light On/Dark On, Power Requirement 5 to 24VDC, Circuit Type NPN, Electrical Connection Spade, Max. Sensing Distance 5mm, Length 0.51 In., Min. Object Size 2 x 0.80mm Opaque, Max. Load Current 100mA, Operating Frequency 1 Hz, Width 0.54 In., Depth 0.61 In., IP Rating 50, Body Material PBT, Light Source Infrared LED'
Details
- Price For: Each Sensing Method: Through Beam Standards: UL Listed, CSA Certified, CE Approval Max. Sensing Distance: 5mm Body Material: PBT Operating Temp. Range: -25 Degrees to 55 Degrees C Power Requirement: 5 to 24VDC Item: Photoelectric Sensor Light Source: Infrared LED Footnotes: -
- Features: Operation Indicator Will Turn On When the Light is Interrupted, Polycarbonate Cover and Emitter/Receiver, No Incident light Circuit Type: NPN IP Rating: 50 Shape: Close-Mounting Operation Mode: Selectable Light On/Dark On Width: 0.54" Length: 0.51" Min. Object Size: 2 x 0.80mm Opaque Depth: 0.61" Electrical Connection: Spade Max. Load Current: 100mA Operating Frequency: 1 Hz
- Country of Origin (subject to change): China
Listing
| Product group | BISS Basic |
|---|---|
| Product type | ELECTRONIC_COMPONENT |
| Model | EE-SX674A |
| Part number | EE-SX674A |
| Label | OMRON |
| Manufacturer | OMRON |
Catalog
| Feature | Price For: Each Sensing Method: Through Beam Standards: UL Listed, CSA Certified, CE Approval Max. Sensing Distance: 5mm Body Material: PBT Operating Temp. Range: -25 Degrees to 55 Degrees C Power Requirement: 5 to 24VDC Item: Photoelectric Sensor Light Source: Infrared LED Footnotes: - |
|---|---|
| Category | Industrial & Scientific |
| MPN | EE-SX674A |
| UPC | 94705338391 |
| EAN | 94705338391 |
| Product group | BISS |
| Product type | ELECTRONIC_COMPONENT |
| Manufacturer | OMRON |
Omron EESX674A Photomicro Sensor, 5 mm Through-Beam, 2 × 0.8 mm Object, NPN Output
Brand: Omron
Omron EE-SX67 Non-modulated photo micro sensor has a 5 mm through-beam sensing with opaque 2 × 0.8 mmSeries includes models that enable switching between dark-ON and light-ON operationEasy operation monitoring with bright light indicatorFlexible robot cable is provided as a standard featureGlobal standard Slot-type photo microsensors with 50- to 100 mA direct switching capacityPolycarbonate cover and emitter/receiverLight indicator (red) (turns ON when light is interrupted for models with A or R suffix). Brand Name|Omron#MFR Part Number|EESX674A#UNSPSC|39121528#Item|Photomicro Sensor#Type|Non-Modulated, Slot#Sensing Method|Through-Beam#Sensing Distance|5 mm#Object Size|Opaque: 2 × 0.8 mm#Output Type|NPN#Operation Mode|Light-ON/Dark-ON#Voltage Rating|5 - 24 VDC#Load Current|100 mA#Frequency Rating|1 kHz#Electrical Connection|4-Pole Connector#Light Source|Infrared LED#Enclosure Rating|IP50#Temperature Rating|-25 to 55 deg C#Mounting Type|Surface#Material|PolyButylene Terephthalate#Dimensions|27.7 mm Height x 13.6 mm Width x 15.5 mm Depth#Standard/Approvals|cUL/UL Listed#Application|For Outdoor Use
Listing
| Binding | Electronics |
|---|---|
| Product group | BISS Basic |
| Product type | ELECTRONIC_COMPONENT |
| Model | EE-SX674A |
| Part number | EE-SX674A |
| Items per pack | 1 |
| Label | Omron |
| Manufacturer | Omron |
Catalog
| Category | Industrial & Scientific |
|---|---|
| MPN | EE-SX674A |
| Product group | BISS |
| Product type | ELECTRONIC_COMPONENT |
| Manufacturer | Omron |
OMRON INDUSTRIAL AUTOMATION - EE-SX674A - OPTICAL SENSOR TRANSMISSIVE / SLOTTED INTERRUPTER
Brand: Omron
Photoelectric Sensor Thru-beam Light ON Dark ON NPN 0.005m 4-Pin
Listing
| Binding | Misc. |
|---|---|
| Product group | BISS |
| Product type | TOOLS |
| Model | EE-SX674A |
| Part number | EE-SX674A |
| Label | OMRON INDUSTRIAL AUTOMATION |
| Manufacturer | OMRON INDUSTRIAL AUTOMATION |
Catalog
| Feature | Price For: Each Sensing Range Max: 5mm Output Current: 100mA Sensor Output: NPN Supply Voltage DC Min: 5V Supply Voltage DC Max: 24V Input Current: 35mA Input Current Max: 35mA No. of Channels: 1 RoHS Compliant: Yes |
|---|---|
| Category | Industrial & Scientific |
| MPN | EE-SX674A |
| UPC | 713141210527 |
| EAN | 713141210527 |
| Product group | BISS |
| Product type | TOOLS |
| Manufacturer | OMRON INDUSTRIAL AUTOMATION |
Optical Switches, Transmissive, Phototransistor Output Slotted 5mm On NPN C-Mount
Brand: Omron
Catalog
| Feature | Manufacturer: Omron Product Category: Sensors - Amplified Photomicrosensors RoHS: Output Device: Phototransistor Slot Width: 5 mm Aperture Width: 0.8 mm Maximum Collector Current: 100 mA Mounting Style: Panel Maximum Operating Temperature: + 55 C Minimum Operating Temperature: - 25 C Series: Brand: Omron Automation and Safety Sensing Distance: 5 mm |
|---|---|
| Category | Industrial & Scientific |
| MPN | EE-SX674A |
| Product group | BISS |
| Product type | ELECTRONIC_COMPONENT |
| Manufacturer | Omron Automation and Safety |
