Mean Well Power Supply, Ac-Dc, 15V, 0.67A - MDR-10-15

<b>Features</b><br>LPV-60/100: 90~264VAC input<br>LPV-150: 180~305VAC input only<br>Fully encapsulated with IP67 level<br>Protections: Short circuit / Overload / Over voltage /Over temperature (LPV-150 only)<br>Constant voltage mode<br>Class 2 power unit / Pass LPS (LPV-60-12/15/24/36/48 only)<br>Isolation class II, no F.G.<br>Withstand 300VAC surge input for 5 seconds (LPV-60/100)<br>Cooling by free air convection<br>100% full load burn-in test<br>Low cost, high reliability<br>Suitable for LED-based decorative/architectural lighting,LED stage, theater lighting, and LED electronic displays<br>2 years warranty<br>The transaction does not include any Import Tax / Duty / VAT / Brokerage Fees / Handling Fees. For more information about the tax rate, please check with local custom department before purchases. If you reject the package due to any charged tax or duty, we reserve the right to charge ALL shipping cost and 5% (of total price) handling fee. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. We do not responsible for any custom duty or import tax. Please check with your country's customs office to determine what these additional costs will be prior to buying. Sometime customs will inspect the parcel and sometime will not. If you have any special request, please kindly advise us once place order.

<p><b>Features:</b></p> <p>Universal AC input / Full range</p> <p>Installed on DIN rail TS35 / 7.5 or 15</p> <p>Protections: Short circuit / Overload / Over voltage</p> <p>No load power consumption <0.75W</p> <p>LED indicator for power on</p> <p>DC OK signal output</p> <p>Cooling by free air convection</p> <p>100% full load burn-in test</p> <p>3 years warranty </p> <p></p> <p><b>General Specification:</b></p> <p>AC input voltage range:85~264VAC; 120~370VDC</p> <p>AC inrush current:Cold start, 35A at 115VAC, 70A at 230VAC</p> <p>DC adjustment range:Fixed</p> <p>Overload protection:>105% hiccup mode, auto-recovery</p> <p>Over voltage protection:115%~135% rated output voltage</p> <p>Setup, rise, hold up time: 500ms, 30ms, 120ms</p> <p>Withstand voltage:I/P-O/P:3kVAC, I/P-FG:1.5kVAC, 1minute</p> <p>Working temperature:-20~+70°C (refer to output derating curve)</p> <p>DC OK signal:Open collector</p> <p>Safety standards:UL508, TUV EN60950-1 approved</p> <p>EMC standards:EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61204-3</p> <p>Connection:I/P: 3 poles, O/P: 3 poles screw DIN terminal</p> <p>Dimension (LxWxH) :22.5x90x100</p> <p>Packing:72pcs / 13.2kg</p>

<b>Features</b><br>LPV-60/100: 90~264VAC input<br>LPV-150: 180~305VAC input only<br>Fully encapsulated with IP67 level<br>Protections: Short circuit / Overload / Over voltage /Over temperature (LPV-150 only)<br>Constant voltage mode<br>Class 2 power unit / Pass LPS (LPV-60-12/15/24/36/48 only)<br>Isolation class II, no F.G.<br>Withstand 300VAC surge input for 5 seconds (LPV-60/100)<br>Cooling by free air convection<br>100% full load burn-in test<br>Low cost, high reliability<br>Suitable for LED-based decorative/architectural lighting,LED stage, theater lighting, and LED electronic displays<br>2 years warranty<br>The transaction does not include any Import Tax / Duty / VAT / Brokerage Fees / Handling Fees. For more information about the tax rate, please check with local custom department before purchases. If you reject the package due to any charged tax or duty, we reserve the right to charge ALL shipping cost and 5% (of total price) handling fee. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. We do not responsible for any custom duty or import tax. Please check with your country's customs office to determine what these additional costs will be prior to buying. Sometime customs will inspect the parcel and sometime will not. If you have any special request, please kindly advise us once place order.

This item will ship MDR-10-15*1pcs + Free gift,enjoy shopping and best wishes!

10W single output industrial DIN rail power supply 5 Volts 2 Amps features: universal AC input/full range protections: short circuit/overload/over voltage cooling by free air convection can be installed on DIN rail ts-35/7.5 or 15 NEC Class 2/LPS compliant LED indicator for power on no load power consumption 100 percent full load burn-in Test 3 years warranty built in DC OK active signal detailed specifications: primary output voltage (VDC): 5 output current (a): 2 maximum output power (W): 10 family: mdr-10 input voltage (VAC): 85 to 264 input frequency: 47 to 63 maximum input current (a): .33 output connector Type: screw terminal efficiency ( percent ): 77 operating temperature-min (CEL): -20 operating temperature-max (CEL): 70 Length (inch): 0.89 width (inch): 3.54 height (inch): 3.94 agency approvals: UL/cul/TUV/CB/CE color: white style: DIN.
