Amphenol Industrial Circular Connector, Receptacle, Size 22, 55 Position, Box - MS3122E22-55P

CIRCULAR CONNECTOR, RECEPTACLE, SIZE 22, 55 POSITION, BOX; Military Specification:MIL-DTL-26482 Series I; Circular Connector Shell Style:Box Mount Receptacle; No. of Contacts:55Contacts; Circular Contact Type:Crimp Pin RoHS Compliant: No

Product Overview The MS3122E22-55P is a 55-contact Circular Connector with gold-plated copper alloy contacts, box mounting receptacle, 22-55 insert arrangement and plug contact type. The crimp type miniature connector provide performance and versatility needed for applications demanding high reliability and crimp removable contacts. This crimp contacts are rear insertable/front release and are held in position by an MS approved spring tower retention system. A corrosion-resistant electrically conductive finish of cadmium plate with an olive drab chromate after-treatment. Shell components for these series are aluminum. The dependable 5-key/keyway polarization with bayonet lock coupling assures positive mating with no chance of cross plugging. Spring tension provided by a wave washer in the coupling nut ensures maintenance of interfacial seal between mating halves. Environmental resisting connector Resilient inserts which provide high dielectric strength and moisture barrier Both insert and main joint gasket are molded from resilient neoprene Meets MIL-C-26482 series 1 Applications Defence, Military & Aerospace, Sensing & Instrumentation, System Monitoring, Automation & Process Control, Communications & Networking, Robotics, Mining, Oil & Gas, Logistics This listing is for Pack of 25. rohsCompliant: NO Circular Contact Type: Crimp Pin hazardous: false rohsPhthalatesCompliant: NO No. of Contacts: 55 Coupling Style: Bayonet Product Range: MIL-DTL-26482 Series I usEccn: EAR99 Connector Body Plating: Olive Drab Chromate over Cadmium Military Specification: MIL-DTL-26482 Series I Contact Material: Copper Alloy Circular Connector Shell Style: Box Mount Receptacle Insert Rotation: N Connector Body Material: Aluminum Alloy Body Service Class: Environmentally Sealed productTraceability: No distributorStatus: AUTHORIZED Insert Arrangement: 22-55 Contact Plating: Gold SVHC: Cadmium
