ANALOG DEVICES . ADALM2000

ADI’s ADALM2000 (M2K) is a classroom full of electronic equipment packed in a hand-held device. The ADALM2000 features a digital oscilloscope, function generator, logic analyzer, voltmeter, network, spectrum and digital bus analyzer, and two programable power supplies. The M2K is so small it will fit in a shirt pocket, and is entirely self-contained and USB powered. The learning module connects to a host via the ‘Scopy’ application software and is Mac, Linux, and Windows compatible. The ADALM2000 is the ideal choice for the teachers, students, hobbyists, and those that are serious about electronics. <p>Features <br>Hand-held <br>2-channel USB oscilloscope <br>2-channel function generator <br>16-channel digital logic analyzer <br>16-channel pattern generator <br>16-channel virtual digital I/O <br>Single channel voltmeter (AC, DC, ±20 V) <br>Network analyzer: Bode, Nyquist, Nichols <br>Spectrum analyzer <br>Digital bus analyzers interfaces: SPI, I²C, UART, parallel <br>Two programmable power supplies (0…+5 V, 0…-5 V) <p>Applications <br>Teachers <br>Students <br>Self-learners <br>Hobbyists <br>Makers

TheADALM2000(M2K) active learning module is an affordable, USB-powered, software-defined instrumen. With 12-bit ADCs and DACs running at 100 MSPS, the M2K brings the power of high performance lab equipment to the palm of your hand, enabling electrical engineering students and hobbyists to explore signals and systems up to tens of MHz without the cost and bulk associated with traditional lab gear. The M2K, working with open-source Scopy graphical application software, provides the user with many high performance instrumentation options. <p>Features: <br>USB 2.0 device and OTG (LAN and Wi-Fi supported) <br>Two general-purpose analog inputs:Differential, ±25 V, 1 MΩ || 30 pF, 12-bit, 100 MSPS ADC with 25 MHz bandwidth <br>Two general-purpose analog outputs:Single-ended, ±5 V, 50 Ω, 12-bit, 150 MSPS DAC with 30 MHz bandwidth <br>Two variable power supplies0 V to 5 V, –5 V to 0 V, 50 mA <br>16 digital input or output pins3.3 V, 1.8 V, 100 MSPS, 5 V tolerant <br>Two digital triggers3.3 V or 1.8 V, 100 MSPS, 5 V tolerant <br>Scopy uses the above features to create:Voltmeters Digital oscilloscopesSpectrum analyzersPower suppliesFunction generatorsArbitrary waveform generators2-port network analyzersDigital logic analyzers with bus analyzersDigital pattern generatorsDigital static inputs/outputs <p>Download SCOPY open source application from Analog Devices GitHub page
