Square D 9007CR53L Side Rotary Spring Return Lever Limit Switch

<p>Hazardous Location Limit Switch, Actuator Style - Limit Switch Wobble Stick, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch 10A @ 600V, DC Contact Rating - Limit Switch 10A @ 600V, Contact Form- Switches 1NC/1NO, Actuator Length - Limit Switch 5.05 In., Body Height - Limit Switch 4.25 In., Body Width - Limit Switch 2.72 In., Body Depth - Limit Switch 2.08 In., Boot Sealed Actuator - Limit Switch No, Threaded for Panel Mounting - Limit Switch No</p><p><b>Specifications: </b><ul><li>Item: Hazardous Location Limit Switch</li><li>Voltage Rating: 600VAC/DC</li><li>Height: 6.10"</li><li>Amps: 10</li><li>Depth: 2.08"</li><li>DC Contact Rating: 10A @ 600V</li><li>Operating Force: 0.44 in.-lb.</li><li>Standards: UL, CSA</li><li>Wiring Entry: 1/2" NPT</li><li>Contact Form: 1NC/1NO</li><li>Actuator Style: Wobble Stick</li><li>Movement: Any Direction</li><li>IP Rating: 67</li><li>Actuator Location: Top</li><li>Operating Temp. Range: 0 Degrees to 185 Degrees F</li><li>NEMA Rating: 1, 2, 4, 6, 6P, 7, 9, 12, 13</li><li>Series: 9007CR</li><li>Body Material: Aluminum</li><li>AC Contact Rating: 10A @ 600V</li><li>Electrical Connection: Screw Terminals</li><li>Travel: Total Travel 90 Degrees</li><li>Actuator Length: 5.05"</li><li>Width: 2.72"</li><li>Certification: UL Class I Groups B, C, D and Class II Groups E, F, G</li></ul></p>

This heavy-duty limit switch features a wobble-stick actuator and zinc body construction.<br /><br /> Limit Switch Style: Hazardous Location Limit Switch<br /> Basic Actuator Style - Limit Switch: Wobble Stick<br /> Actuator Style - Limit Switch: Wobble Stick<br /> Actuator Location - Limit Switch: Top<br /> Item: Hazardous Location Limit Switch<br /> AC Contact Rating - Limit Switch: 10A @ 600V<br /> DC Contact Rating - Limit Switch: 10A @ 600V<br /> Contact Form- Switches: 1NC/1NO<br /> Actuator Length - Limit Switch: 5.05"<br /> Body Height - Limit Switch: 4.25"<br /> Body Width - Limit Switch: 2.72"<br /> Body Depth - Limit Switch: 2.08"<br /> Boot Sealed Actuator - Limit Switch: No<br /> Threaded for Panel Mounting - Limit Switch: No<br /> Body Style - Limit Switch: Standard<br /> NEMA Rating: 1, 2, 4, 6, 6P, 7, 9, 12, 13<br /> Wiring Entry: 1/2" NPT<br /> Electrical Connection: Screw Terminals<br /> IP Rating: 67<br /> Movement: Any Direction<br /> Travel: Total Travel 90 Degrees<br /> Series: 9007CR<br /> Operating Temp. Range: 0 Degrees to 185 Degrees F<br /> Body Material: Aluminum<br /> Operating Force: 0.44 in.-lb.<br /> Standards: UL, CSA<br /> Certification: UL Class I Groups B, C, D and Class II Groups E, F, G<br />
