Circuit breaker, PowerPacT P, 600A, 3 pole, 480VAC, 100kA, I-Line, Micrologic 6.0H, 100%, ABC, modbus | Mayer Electric

SQUARE D . SQDPLA34060CU74AE1

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
Attribute00circuit breaker
Attribute01PowerPact P
Attribute02distribution
Attribute03PowerPact
Attribute0418 months
Attribute05I-Line bracket)
Attribute0650/60 Hz
Attribute0725 mm
Attribute08AL800M23K
Attribute09600-600 A
Attribute1065 kA 240 V AC 50/60 Hz IEC 60947-2 || 45 kA 380/415 V AC 50/60 Hz IEC 60947-2
Attribute110.4...1 x Ir
Attribute12electronic, harmonic, Micrologic 6.0 H, LSIG
Attribute13Micrologic 6.0 H
Attribute1412.86 in
Attribute15100 %
Attribute16AIR 125 kA 240 V AC 50/60 Hz UL 489 || AIR 100 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 125 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 85 kA 380/415 V AC 50/60 Hz IEC 60947-2
Attribute17750 V IEC 60947-2
Attribute18480 V AC 50/60 Hz UL 489
Attribute19Modbus
Attribute2050-50 N.m 95-240 mm? (3 x AWG 3/0...3 x 500 kcmil) || 1.0-1.3 N.m
Attribute21bracket
Attribute22L
Attribute23Modbus connecting cable
Attribute243P
Attribute25overload 1 1 LED amber) || 1 flag green) || trip causes 4 trip indicator red)
Attribute26, moq, multiple, tierMinQty11
Attribute272 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Attribute283 x AWG 3/0...3 x 500 kcmil aluminium/copper
Attribute298.27 in
Attribute30I-Line connection line || lugs load
Attribute318.05 in
Attribute329 in
Attribute3332 lb(US)
Attribute348 kV IEC 60947-2
Attribute35toggle
Attribute36ABC
Attribute37Product out of China RoHS scope. Substance declaration for your information.
Attribute38ENVEOLI1407012EN
Attribute39, Attribute40, Attribute43Yes
Attribute41ENVPEP1407012EN
Attribute42Green Premium product
Attribute44Compliant
Attribute45Reference contains Substances of Very High Concern above the threshold
Attribute46DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Attribute47-2-70 ?C
Attribute483 IEC 60947-1
Attribute49-50-85 ?C
Attribute50UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Attribute51CE
Attribute52UL || CSA || NOM
Attribute53front cover IP40
AttributeKey00Product Or Component Type
AttributeKey01Product Name
AttributeKey02Device Application
AttributeKey03Range
AttributeKey04Warranty
AttributeKey05Mounting Mode
AttributeKey06Network Frequency
AttributeKey07Wire Stripping Length
AttributeKey08Terminal Identifier
AttributeKey09Line Rated Current
AttributeKey10[Ics] Rated Service Breaking Capacity
AttributeKey11Long Time Pick-Up Adjustment Range
AttributeKey12Trip Unit Technology
AttributeKey13Trip Unit Name
AttributeKey14, height_AttribHeight
AttributeKey15Continuous Current Rating
AttributeKey16Breaking Capacity
AttributeKey17[Ui] Rated Insulation Voltage
AttributeKey18[Ue] Rated Operational Voltage
AttributeKey19Communication Interface
AttributeKey20Tightening Torque
AttributeKey21Mounting Support
AttributeKey22Breaking Capacity Code
AttributeKey23Accessory / Separate Part Type
AttributeKey24Poles Description
AttributeKey25Local Signalling
AttributeKey26Quantity Per Set
AttributeKey27Number Of Slots
AttributeKey28Awg Gauge
AttributeKey29, width_AttribWidth
AttributeKey30Electrical Connection
AttributeKey31, length_AttribDepth
AttributeKey32Mounting Height
AttributeKey33, Weight_AttribNet Weight
AttributeKey34[Uimp] Rated Impulse Withstand Voltage
AttributeKey35Control Type
AttributeKey36Phase Connection
AttributeKey37China Rohs Regulation
AttributeKey38Circularity Profile
AttributeKey39Rohs Exemption Information
AttributeKey40Mercury Free
AttributeKey41Environmental Disclosure
AttributeKey42Sustainable Offer Status
AttributeKey43Pvc Free
AttributeKey44Eu Rohs Directive
AttributeKey45Reach Regulation
AttributeKey46California Proposition 65 : WARNING: This product can expose you to chemicals including
AttributeKey47Ambient Air Temperature For Operation
AttributeKey48Pollution Degree
AttributeKey49Ambient Air Temperature For Storage
AttributeKey50Standards
AttributeKey51Quality Labels
AttributeKey52Product Certifications
AttributeKey53Ip Degree Of Protection
DimensionUnitinch
Extra Product NameCircuit breaker, PowerPacT P, 600A, 3 pole, 480VAC, 100kA, I-Line, Micrologic 6.0H, 100%, ABC, modbus | Mayer Electric
UPC, MPN, SKUSQDPLA34060CU74AE1
Weight32
WeightUnitlbs
depth, length8.05
height12.86
jsonUrlData/Product/SQUARE-D-Circuit-breaker-PowerPact-P-600A-3-pole-480VAC-100kA-I-Line-Micrologic-6-0H-100-ABC-modbus-SQDPLA34060CU74AE1
jsonUrlData28234152a-7d2e-4cb3-8f2f-aeea005731ea
qtyInStock0
tierPrice10.0
width8.27

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDPLA34060CU74AE1111 @ $0.00
