Sumitomo

Sumitomo . CCMT32.51EMU-AC8025P

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameSumitomo
DimensionUnitinch
GraingerSku52EV67
UPCNone
UnitOfMeasureEA
Weight0.11
WeightUnitlbs
cali_prop65_messageWARNING: Cancer - www.P65Warnings.ca.gov
cali_prop65_orglabelFalse
cali_prop65_warnmsgscenario5
cali_prop65_whtlabelTrue
countryOfOriginJP
height0.6
jsonUrlData924526ffbdad25e5923b
length3.7
moq, multiple, qtyInStock10
MPN, ANSI NumberCCMT32.51EMU-AC8025P
qtyInStockOverride-2
SKUG6332210
tierMinQty1, Corner Radius1
tierPrice18.43
urlhttps://www.zoro.com/sumitomo-diamond-turning-insert-diamond-38-in-ccmt-80-degrees-164-in-carbide-ccmt3251emu-ac8025p/i/G6332210/
width1.7
ItemDiamond Turning Insert
Insert ShapeDiamond
Insert StyleCCMT
Inscribed Circle3
Insert Size32.51
Included Angle80 Degrees
Chip-Breaker, Cast Iron (K) Compatibility, Steel (P) Compatibility, Stainless (M) CompatibilityYes
Grade, Manufacturer GradeAC8025P
Material, Insert Material, Material - MachiningCarbide
Workpiece CompatibilityCast Iron (K), Stainless (M), Steel (P)
Insert ApplicationRoughing
Mounting StyleTop and Hole Clamping
Insert Thickness0.1560"
ISO NumberCCMT09T304NMU
No of Edges, Number of Cutting Edges4
Hardened (H) Compatibility, Non Ferrous (N) Compatibility, Super Alloy (S) CompatibilityNo
Mounting Hole Dia0.173"
Rake0 Degrees
For Use WithToolholders, Boring Bars
Coating, Coating ProcessCVD
Nose Radius0.0156"
Cutting DirectionNeutral
Cutting ApplicationTurning
FeaturesAdhesion Resistant, Chipping Resistant
Primary Material ApplicationSteel
Chip-Breaker CodeEMU
Primary Material Application ISO CodeP25
Chip-Breaker StyleSingle
Clearance Angle7 Degrees
ShapeRhombic
ANSI CodeCCMT32.51EMU
Finish - MachiningAbsotech Platinum
Measurement SystemFractional Inch
Thickness2.5
Insert Holding TypeCountersink Hole
Insert CodeCCMT32.51
Country of Origin (subject to change)Japan

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG63322101010101 @ $8.43
ZoroG301015694111 @ $94.88
