3M MNG14-6FB/SX

B00FYHPHDE

3M Scotchlok Blue Locking Butted Nylon Butted Fork & Spade Terminal - 0.86 in Length - 0.25 in Fork Width - #6 Stud - MNG14-6FB/SX [PRICE is per CASE]

3M Scotchlok Blue Locking Butted Nylon Butted Fork & Spade Terminal - 0.86 in Length - 0.25 in Fork Width - #6 Stud - MNG14-6FB/SX [PRICE is per CASE]zoom

Attributes

Key Value
3M NumberMNG14-6FB/SX
Barrel Length TypeButted
Barrel TypeButted Seam
Brand3M
Brand Name3M
Clearance0.25 in
ColorBlue
Color CodeNo
Conductor Size16-14 AWG
Country Of OriginUnited States of America
Country of OriginUS - United States
Dimensions0.86 Inch Length
ECCNEAR99
Energy Star FlagNo
Fastening MechanismLocking
FinishTin Plated
Fork Width0.25 in
GTIN00051128589717
Inside Diameter0.09 in
Insulation Length0.71 in
Insulation MaterialNylon
Item NameFork And Spade Terminal
Made In AmericaYes
Manufacturer Name3M
Manufacturer Part NumberMNG14-6FB/SX
MaterialCopper
Maximum Insulation Outs.0.17 in
Maximum Wire Size14 AWG
Minimum Conductor Leg D.16 AWG
Minimum Wire Size16 AWG
Overall Length0.86 in
Overall Width0.25 in
Package Quantity100 per bottle, 500 per.
RoHS FlagYes
Size6
Standard Pack/Case Quan.100/Carton, 500/Case
StandardsUL Listed, CSA Certifie.
Stud Size#6
Sub BrandScotchlok?
Tang Size0.25 Inch Width x 0.03 .
Tang TypeNo
Temperature Rating-40 to 105 deg C
Trade NameScotchlok
TypeFork, Insulated, Block
UNSPSC39121432
UPC05112858971
Voltage Rating600 Volt

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomPlatt.com03447620.2612003M0.26 @ 1
Monarch Electric4311620.9211083M0.92 @ 1
thumbzoomgordonelectricsupply.comMNG14-6FB/SX94.091In Stock4553-M94.09 @ 1
thumbzoomNewark66W6327146.495In Stock3M146.49 @ 5
Graybar25323582150.89761In Stock3M150.8976 @ 1
thumbzoomrshughes.com051128-58971455.0100In Stock3M455.0 @ 100
