Aalborg VPT4-TA-V08-02-TF
Aalborgzoom
brand:
manufacturer:
Description:
<p><strong>Aalborg, VPT4-TA-V08-02-TF, V Direct Reading Multi-Gas, Medium Range, Panel Mount Flow Meter with Valve </strong> </p> <p>Incorporating traditional variable area precision glass technology, this rugged PTFE flow meter offer accurate and economical solutions to medium flow range measurements. V meter are designed with unique rotatable scales of dual air-water direct reading graduations showing SCFM and L/min (air), as well as GPM and LPM (water) markings. </p> <p><strong>Leak Integrity: </strong> Flow meter are individually tested on a Mass Spectrometer Leak Detector and certified to a leak integrity rating of 1 x 10-7 sccs Helium or better. </p>

Attributes

Key ^Value
Accuracy?5% of full scale
Connections3/8" NPT female in line or horizontal rear
End Fitting Material, Floats, SealsPTFE
Flow TubesHeavy walled precision formed borosilicate glass
Leak IntegrityIndividually leak tested and certified
Maximum Pressure100 psig (6.7) bars
Maximum Temperature150 ?F (65 ?C)
Tube ShieldsPolycarbonate
