ABB PSR12-600-70

B01DL6U0A4

Soft Starter, Compact, PSR Series, 12 A, 5.5 kW, 208 VAC to 600 VAC, 100-240 VAC

Soft Starter, Compact, PSR Series, 12 A, 5.5 kW, 208 VAC to 600 VAC, 100-240 VACzoom

Attributes

Key Value
Adjustable rated motor .No
Alternate Mfr Part Numb.1SFA896106R7000
Amps (Max)11
ApprovalsCE, cUL, UL
ASINB079Q82MV3
By-PassBuilt-In
By-pass signal relayNo
BypassNo
CommunicationFiledBusPlug(Optional)
CommunicationsField Bus
Connecting capacity con.1 x 0.75 ... 2.52 x 0.7.
Connecting capacity mai.Rigid 1/2 x 0.75 ... 2..
Connecting capacity sup.Rigid 1/2 x 0.75 ... 2..
Control Voltage100-240VAC, 240 VAC, 12.
Current limit functionNo
Current Rating12 A
Degree of protectionIP20
EnclosureNo
Enclosure TypeOpen
Estimated Weight2.00
Family SeriesABB Soft Starters, PSR .
Fault signal relayNo
FunctionSingle direction
Gross Weight1.09 lbs
Horsepower Rating10.0 Max
HP @ 230V3
HP @ 460V7.5
Initial voltage during .40 ... 70 %
Integrated electronic o.No
Is Discontinued By Manu.No
Item model numberPSR12-600-70
Item NumberPSR12-600-70
ManufacturerABB
Manufacturer Part NumberPSR12-600-70
Max Current11 A
Max HP 200/208V 3PH3 hp
Max HP 230/240V 3PH3 hp
Max HP 460/480V 3PH7.5 hp
Max HP 575/600V 3PH10 hp
Maximum Operating Tempe.60 ?C
Minimum Operating Tempe.-25 ?C
Mounting TypeDIN Rail Mount
Net Weight0.915 lbs
Nominal Control Voltage120 VAC, 208 VAC, 240 V.
Nominal Load Voltage208 V, 240 V, 380 V, 48.
Number of starts per ho.10
Overall Depth140 mm
Overall Dimensions45 x 114 x 140 mm
Overall Length45 mm
Overall Width114 mm
Overload Capacity400% for 6 Seconds
Overload protectionRecommended MS132 10.00.
Overload ProtectionNo
Overload signal relayNo
Phase2 Phase
Power Rating5.5 kW
Primary TypeStarter
Product main typePSR12
Product SeriesPSR
Ramp time0 ... 20 second [unit o.
Rated control circuit v.24 V DC
Rated control supply vo.100 ... 240 V AC
Rated operational curre.12 A
Rated operational power.(230 V) 3 kW(400 V) 5.5.
Rated operational volta.208 ... 600 V AC
Rating11.0 A
Run signal relayYes
SeriesPSR Series
Service factor percenta.100.00%
Signal indication compl.Green
Signal indication rampi.Green
Signal indication ready.Green
Signal indication runni.Green
Size0.39 L x 5.51 H in., 10.
Special FeaturesPotentiometer Setting, .
StandardsC-Tick, CCC, CE, CSA, G.
Starting capacity at ma.4xIe for 6s
Step down voltage speci.100 ... 60 %
Supply Voltage208-600 V
Switch for inside delta.No
Temperature (F)-13-140 ?F
Temperature Operating R.-25 to +60 ?C
Terminal TypeScrew
Tightening torqueControl Circuit 1 N?mMa.
TypePSR, Soft Start
Voltage Rating600 V

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomAmazonB079Q82MV3185.151In StockABB185.15 @ 1
thumbzoomMRO Supply6151897238.041In StockABB238.04 @ 1
thumbzoomWalker IndustrialPSR12-600-70268.071In StockABB268.07 @ 1
thumbzoomturtle.comABB PSR12-600-70270.061In StockABB270.06 @ 1
thumbzoomPurvisPSR12-600-70286.21In StockABB286.2 @ 1
thumbzoomGalcoPSR12-600-70-ABBG294.6813ABB1.09294.68 @ 1
Airline HydraulicsABB PSR12-600-70295.431In StockABB295.43 @ 1
standardelectricsupply.com2348460296.881In StockABB296.88 @ 1
thumbzoommotorsandcontrol.comPSR12-600-70306.0211ABB2.0306.02 @ 1
thumbzoomalldataresource.com536827307.21In StockABB307.2 @ 1
thumbzoomenergycontrol.comPSR12-600-70329.01In StockABB329.0 @ 1
us.rs-online.com70094405332.1112ABB332.11 @ 1
AmazonTPB00JV3G6L4339.691In Stock5ABB339.69 @ 1
thumbzoomindustrialstores.comPSR12-600-70344.371In Stock12ABB344.37 @ 1
