mpn:
brand:
manufacturer:
MPN:
Weight:
5.0
Weight:
5.0 LB
Preferred Price:
48.44
Price:
48.44
Min Simple Price:
23.74
Absolute Min Price:
38.71
Min Price:
38.71
Dimensions:
[6.0, 4.0, 1.0]
qty:
21
simpleSku:
NTM1Nw:::60110-6-1/4
sku:
NTM1Nw::0A:60110-6-1/4@y0
condition:
11
seller:
fixsupply.com
amzMan:
aignep usa
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Application | Air |
| Basic Material, Body, Body Material, Fitting Material, Material, Pipe Thread Material, Ring Release Material | Stainless Steel |
| Body Color, Color, Ring Release Color | Silver |
| Brand Name | AIGNEP |
| Brand Part Number, Manufacturer Part Number, Mfr. Model? | 60110-6-1/4 |
| Brand, Displayed Brand | AIGNEP USA |
| Catalog Page | N/A |
| Compatible Tube Material | Copper; Nylon; Polyethylene; Polyurethane, Copper, Nylon, Polyethylene, Polyurethane |
| Compliance | EN331, REACH, ROHS |
| Connection (A) | 5/16" Tube |
| Connection (B) | 1/4" BSPT Male |
| Connection Type | Tube x BSPT |
| Country of Origin, Country of Origin (subject to change) | Italy |
| End Connection Type | Push-to-Connect, Threaded |
| Fitting Body Material, Gripping Ring Material | 316L Stainless Steel |
| Fitting Pipe Size, Fitting Side B Pipe Size | 1/4 in |
| Fitting Shape, Shape | Elbow |
| Fitting Side A Connection Type | Push-to-Connect |
| Fitting Side A Tube Outer Diameter, For Tube OD, For Tube Outside Diameter | 6 mm |
| Fitting Side B Connection Type | Universal |
| Fitting Thread Size | 1/4-19 |
| Fittings Sub-Category | Elbows |
| For Tube OD | 5/16" |
| Gasket Material, Release Ring Material | PTFE/FKM |
| Hex Size | 7/16 in |
| Includes Pre-Applied Thread Sealant | Yes |
| Item | Elbow Connector |
| Item? | 49JX93 |
| Material Grade | 316L |
| Max. Pressure | 250 psi |
| Maximum Operating Pressure, Working Pressure | 290 psi |
| Maximum Operating Temperature | 437 Degrees F, 437 ?F |
| Media | Compressed Air Fluid for the food and Chemical Industry compatible with component specifications |
| Minimum Operating Temperature | 5 Degrees F, 5 ?F |
| O-Ring Material | Viton |
| Pipe Size | 1/4 in BSPT, 1/4" |
| Pipe Thread Type | BSPT Male |
| Pressure Rating | Vacuum-290 PSI |
| Specific Fitting Shape | 90? Elbow Adapter |
| Standards | ISO 14743:2004; NSF/ANSI 169; PED 2014/68/UE; REACH 1907/2006; RoHS 2011/65/CE; Silicone Free Certified |
| Style | Male Elbow |
| Sub-brand | Swift fit |
| System of Measurement | Imperial/Metric |
| Temp. Range | 5 Degrees to 437 Degrees F |
| Temperature Range | 5 ? F - 437? F |
| Thread Seal, Thread Sealant Type | FKM |
| Thread Type | SWIFTFIT |
| Tube Size | 6mm |
| Tubing Compatibility | Nylon, Polyethylene, Polyurethane, Copper |
| UNSPSC | 40142613 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | fixsupply.com | ZUSA-TF-PTC-SS-89 | 23.74 | 23.74 | 1 | In Stock | AIGNEP | 23.74 @ Qty: 1+ | ||
 | primebuy.com | 60110-6-1/4 | 28.47 | 28.47 | 1 | In Stock | Aignep | 28.47 @ Qty: 1+ | ||
 | Global Industrial | WBB1223013 | 36.95 | 36.95 | 1 | In Stock | 15 | Aignep USA | 36.95 @ Qty: 1+ | |
 | Zoro | G5095828 | 56.61 | 56.61 | 1 | In Stock | 32 | Aignep Usa | 0.01 | 56.61 @ Qty: 1+ |
| Grainger | 49JX93 | 116.2 | 116.2 | 1 | In Stock | AIGNEP USA | 116.2 @ Qty: 1+ |
