AMI Bearing MUCFBL206B

B01CPRMXUK

AMI: MUCFBL206B, 30MM STAINLESS SET SCREW BLACK 3-BOLT FLANGE BRACKET, NEW!

AMI: MUCFBL206B, 30MM STAINLESS SET SCREW BLACK 3-BOLT FLANGE BRACKET, NEW!zoom

Attributes

Key Value
bolt size:M10
Bolt Spacing1.252 Inch | 31.8 Milli.
Bore1.181 Inch | 30 Millime.
bore type:Round
bracket width:76 mm
BrandAMI BEARINGS
Cartridge Pilot Depth0 Inch | 0 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
CategoryFlange Block Bearings
duty type:Standard Duty
EAN0808250229710
Expansion / Non-expansi.Non-expansion
Global Part Number GPN533672
Harmonized Tariff Code8483.20.40.40
horizontal bolt spacing:47.6 mm
Housing Configuration1 Piece Solid
Housing MaterialThermoplastic
housing material:PBT Thermoplastic
Housing Style3 Bolt Flange Bracket
hub diameter:83 mm
Inch - MetricMetric
Insert Part NumberMUC206
length through bore:38.1 mm
Length Thru Bore1.5 Inch | 38.1 Millime.
locking device:Set Screw
lubrication type:Lubrication Fitting
Manufacturer NameASAHI BEARINGS
Mounting Bolts10 Millimeter
Mounting MethodSet Screw
mounting type:Three-Bolt Bracket Style
Nominal Bolt Circle Dia.0 Inch | 0 Millimeter
Number of Mounting Holes3
Other FeaturesSingle Row | Spherical .
Pilot ConfigurationNo Pilot
price$ 194.88 / each
radial dynamic load cap.1700 kgf
radial static load capa.920 kgf
RelubricatableYes
replacement bearing:MUC206
seal type:Contact with Flinger
SealsContact Seal
series:MUCFBL200B
shaft centerline height:52.4 mm
titleMUCFBL206B
unit standoff:41.5 mm
UNSPSC31171501
vertical bolt spacing:31.8 mm
Weight / kgm0.472
Weight / LBS1.03

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomMRO Supply5856141.491In StockAMI Bearings141.49 @ 1
thumbzoomLily BearingMUCFBL206B165.651In StockAMI BEARINGS1.0384165.65 @ 1
Applied Industrial101499478189.621In StockAMI Bearings Inc.189.62 @ 1
thumbzoommotionindustries.com03770115222.581In StockAMI Bearings222.58 @ 1
