AMI Bearing MUCTBL205-14W

B01CPRM4F4

AMI: MUCTBL205-14W, 7/8" STAINLESS SET SCREW WHITE TAPPED BASE PILLOW BLOCK, NEW

AMI: MUCTBL205-14W, 7/8" STAINLESS SET SCREW WHITE TAPPED BASE PILLOW BLOCK, NEWzoom

Attributes

Key Value
Actual Bolt Center to C.2 Inch | 52Millimeter
base to bore centerline:1.4375 in
Base to Center Height1.438 Inch | 36.525 Mil.
base width:1-9/16 in
bolt center-to-center l.2 in
bolt size:3/8-16
Bolt Spacing Maximum0 Inch | 0Millimeter
Bolt Spacing Minimum0 Inch | 0Millimeter
bore diameter:0.8750 in
bore type:Round
BrandAMI BEARINGS
CategoryPillow Block Bearings
duty type:Normal Duty
Expansion / Non-expansi.Non-expansion
Global Part Number GPN526211
Harmonized Tariff Code8483.20.40.40
Housing Configuration1 Piece Solid
Housing MaterialThermoplastic
housing material:PBT Thermoplastic
Housing Style2 Bolt Tap Base Pillow .
I.D.7/8 in
Inch - MetricInch
Insert Part NumberMUC205-14
Length Thru Bore1.339 Inch | 34 Millime.
locking device:Set Screw
lubrication type:Lubrication Fitting
Manufacturer NameASAHI BEARINGS
Mounting Bolts3/8 Inch
Mounting MethodSet Screw
mounting:Tapped Base
Nominal Bolt Center to .2 Inch | 52 Millimeter
Number of Mounting Holes2
Other FeaturesSingle Row | Spherical .
overall height:2.8906 in
overall length:3.0000 in
overall width:1-9/16 in
price$ 181.46 / each
radial dynamic load cap.2680 lbf
radial static load capa.1420 lbf
RelubricatableYes
replacement bearing:MUC205-14
seal type:Contact with Slinger
SealsContact Seal
series:MUCTBL200W
titleMUCTBL205-14W
UNSPSC31171511
Weight / kgm0.33
Weight / LBS0.73

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomMRO Supply6515131.751In StockAMI Bearings131.75 @ 1
thumbzoomLily BearingMUCTBL205-14W154.241In StockAMI BEARINGS0.726154.24 @ 1
thumbzoommotionindustries.com03773570207.241In StockAMI Bearings207.24 @ 1
