AMI Bearing UCF213C4HR23

B01CPRPN7K

AMI: UCF213C4HR23, 65MM HIGH TEMP (450 DEG) 4-BOLT FLANGE, FACTORY NEW!

AMI: UCF213C4HR23, 65MM HIGH TEMP (450 DEG) 4-BOLT FLANGE, FACTORY NEW!zoom

Attributes

Key Value
Bolt Spacing5.866 Inch | 149 Millim.
Bore2.559 Inch | 65 Millime.
bore type:Round
BrandAMI BEARINGS
Cartridge Pilot Depth0 Inch | 0 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
CategoryFlange Block Bearings
duty type:Standard Duty
EAN0808250271351
Expansion / Non-expansi.Non-expansion
expansion type:Non-Expansion Bearing (.
Global Part Number GPN534515
Harmonized Tariff Code8483.20.40.40
Housing Configuration1 Piece Solid
Housing MaterialCast Iron
housing material:Cast Iron
Housing Style4 Bolt Square Flange Bl.
Inch - MetricMetric
Insert Part NumberUC213C4HR23
length through bore:65.1 mm
Length Thru Bore2.563 Inch | 65.09 Mill.
locking device:Set Screw
lubrication type:Lubrication Fitting
Manufacturer NameASAHI BEARINGS
Mounting Bolts16 Millimeter
Mounting MethodSet Screw
mounting type:Four-Bolt Flange
Nominal Bolt Circle Dia.8.3 Inch | 211 Millimet.
Number of Mounting Holes4
Other FeaturesSingle Row | Spherical .
Pilot ConfigurationNo Pilot
price$ 493.06 / each
radial dynamic load cap.5850 kgf
radial static load capa.4100 kgf
RelubricatableYes
replacement bearing:UC213C4HR23
seal type:Contact with Flinger
SealsContact Seal
series:UCF200C4HR23
titleUCF213C4HR23
UNSPSC31171501
Weight / kgm5.58
Weight / LBS12.3

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomMRO Supply1942357.971In StockAMI Bearings357.97 @ 1
thumbzoomLily BearingUCF213C4HR23419.11In StockAMI BEARINGS12.276419.1 @ 1
Applied Industrial101498327552.041In StockAMI Bearings Inc.552.04 @ 1
thumbzoommotionindustries.com03767926563.111In StockAMI Bearings563.11 @ 1
