TE Connectivity 5-102202-3

B00V3ULXCU

T-E Connectivity 5-102202-3 (2 pcs) 06 MODII HDR SRST SHRD LF

T-E Connectivity 5-102202-3 (2 pcs) 06 MODII HDR SRST SHRD LFzoom

Attributes

Key Value
Alternate Part No.571-5-102202-3
Applications-
Base Product Number102202
BrandTE Connectivity
CategoryConnectors, Interconnec.
Connector TypeHeader
Contact Finish - MatingGold
Contact Finish - PostTin
Contact Finish Thicknes.15.0?in (0.38?m)
Contact Finish Thicknes.100.0?in (2.54?m)
Contact GenderPin (Male)
Contact Length - Mating0.240" (6.10mm)
Contact Length - Post0.130" (3.30mm)
Contact MaterialBrass, Copper Alloy
Contact PlatingGold
Contact ShapeSquare
Contact TypeMale Pin
Country of Origin (subj.Mexico
Current Rating3 A
Current Rating (Amps)3A
DescriptionCONN HEADER VERT 6POS 2.
Detailed DescriptionConnector Header Throug.
Digi-Key Part NumberA32984-ND
Fastening TypePush-Pull
Features-
Flammability RatingUL 94 V-0
Housing MaterialThermoplastic
Ingress Protection-
Insulation ColorBlack
Insulation Height0.549" (13.94mm)
Insulation MaterialThermoplastic
Insulation Resistance5000 MOhms
ManufacturerTE Connectivity AMP Con.
Manufacturer Part No.5-102202-3
Manufacturer Product Nu.5-102202-3
Manufacturer Standard L.18 Weeks
Mated Stacking Heights-
Material Flammability R.UL94 V-0
Mating Post Length6.1 mm
MfrTE Connectivity AMP Con.
Mounting AngleVertical
Mounting TypeThrough Hole
Number of Positions6
Number of Positions Loa.All
Number of Rows1
Operating Temperature-65?C ~ 105?C
Operating Temperature R.- 55 C to + 105 C
Overall Contact Length0.589" (14.96mm)
PackageTube
Pitch2.54 mm
Pitch - Mating0.100" (2.54mm)
Product CategoryHeaders & Wire Housings
Product StatusActive
Product TypeHeaders
Row Spacing2.54 mm
Row Spacing - Mating-
SeriesAMPMODU Mod II
ShroudingShrouded - 4 Wall
StyleBoard to Board or Cable
TerminationSolder
Termination Post Length3.3 mm
Termination StyleThrough Hole
TradenameAMPMODU
TypeShrouded
Voltage Rating-

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Arrow5-102202-31.178957957TE Connectivity1.178 @ 957
Onlinecomponents.com5-102202-31.6415733TE Connectivity / AMP Brand1.47 @ 29
thumbzoomNewark98K95031.651366AMP - TE CONNECTIVITY1.65 @ 25
RS Delivers864-07221.7904125TE Connectivity1.7904 @ 25
thumbzoomDigi-Key10930552.23811913TE Connectivity AMP Connectors2.238 @ 25
Future Electronics67262852.29211662TE Connectivity2.292 @ 25
thumbzoomZoroG9009397972.69325Te Connectivity2.69 @ 25
thumbzoomTME5-102202-33.43158TE Connectivity3.43 @ 25
thumbzoomswatee.com5-102202-33.93185TE Connectivity3.93 @ 25
AmazonTPB00DEFH7A410.481252TE Connectivity / AMP Brand10.48 @ 25
AmazonSCB00V3ULXCU14.01125TE Connectivity14.01 @ 25
