mpn:
brand:
manufacturer:
MPN:
Preferred Price:
230.1
Price:
230.1
Min Simple Price:
0.13
Absolute Min Price:
184.6
Min Price:
184.6
Dimensions:
[1.0, 1.0, 1.0]
qty:
1
simpleSku:
NjI5OA:::640445-6
sku:
NjI5OA::0I:640445-6@y3
condition:
11
seller:
Hawk Electronics
amzMan:
te connectivity / amp
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Agency Approvals | CSA ; UL |
| Alternate Mfr Part Number, Manufacturer Product Number | 640445-6 |
| Angle | Straight |
| Application | For wire-to-board |
| Applications | General Purpose, Industrial |
| Base Product Number | 640445 |
| Category | Connectors, Interconnects |
| Centerline (Pitch) | 3.96?mm?[?.156?in?] |
| Circuit Application | Power |
| Color, Housing Color | White |
| Connector | Printed Circuit Board |
| Connector Mounting Type, Primary Type | Board Mount |
| Connector System | Wire-to-Board |
| Connector Type | Male |
| Connector Type, Product Type | Header |
| Contact Base Material, Contact Material | Copper Alloy |
| Contact Centerline Spacing, Pin Spacing | 0.156 in |
| Contact Current Rating (Max) | 7 |
| Contact Finish - Mating, Contact Finish - Post, Contact Mating Area Plating Material, Contact Plating, Contact Termination Area Plating Material | Tin |
| Contact Finish Thickness - Mating, Contact Finish Thickness - Post, Features, Ingress Protection, Mated Stacking Heights, Row Spacing - Mating | - |
| Contact Length - Mating | 0.400" (10.16mm) |
| Contact Length - Post | 0.125" (3.18mm) |
| Contact Mating Area Plating Thickness | 2.54??m?[?100??in?] |
| Contact Retention, Mating Alignment, Panel Mount Feature, PCB Mount Alignment, PCB Mount Retention | Without |
| Contact Shape | Square |
| Contact Type | Male Pin, Tab |
| Contact Underplating Material | Nickel |
| Country of Origin (subject to change) | China |
| Current Rating | 7 A |
| Current Rating (Amps) | Varies by Wire Gauge |
| Description | CONN HEADER VERT 6POS 3.96MM |
| Detailed Description | Connector Header Through Hole 6 position 0.156" (3.96mm) |
| Digi-Key Part Number | A1973-ND |
| Fastening Type | Friction Lock |
| Glow Wire Rating | Standard Part - Not Glow Wire |
| Header Type | Unshrouded |
| Housing Color, Insulation Color | Natural |
| Housing Material | Polyester, Thermoplastic Polyester |
| Housing Type, Type | Plug |
| Insulation Diameter | 0.095" (Single Wire), 0.07" (Mass Termination Wires) |
| Insulation Height | 0.425" (10.80mm) |
| Insulation Material | Thermoplastic, Glass Filled |
| Manufacturer Standard Lead Time | 6 Weeks |
| Manufacturer, Mfr | TE Connectivity AMP Connectors |
| Material Flammability Rating | UL94 V-0 |
| Mounting Hole Size | 0.07 in |
| Mounting Type | Through Hole, PCB Mount |
| Number of Contacts, Number of Positions, Number of Power Positions | 6 |
| Number of Positions Loaded | All |
| Number of Rows | 1 |
| Operating Temperature | -55 to +105 ?C, -55?C ~ 105?C |
| Operating Temperature Range | -55 ? 105??C?[?-67 ? 221??F?] |
| Operating Voltage | 600 |
| Overall Contact Length | 0.650" (16.51mm) |
| Overall Length | 0.936 " |
| Package | Bulk |
| Packaging Method | Package |
| PCB Mount Orientation | Vertical |
| Pin Length | 0.125 " |
| Pitch | 3.96 mm (0.156") |
| Pitch - Mating | 0.156" (3.96mm) |
| Product Header | MTA-156 Connector Header Assembly |
| Product Status | Active |
| Sealable | No |
| Series | MTA-156 Series, MTA-156 |
| Shrouding | Shrouded - 1 Wall |
| Special Features | IDC, Pinstrip |
| Standards | UL 94V-0 Housing Flammability Rating, RoHS Compliant, ELV Compliant |
| Style | Board to Cable/Wire |
| Terminal Post Length | 0.125 in. |
| Termination | Solder |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Termination Post | 3.56?mm?[?.14?in?] |
| UL Flammability Rating | UL 94V-0 |
| Voltage Rating | 600VAC, 600 V |
| Wire Size | 26-18 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Hawk Electronics | 640445-6 | 0.13 | 83.2 | 100 | 1000 | TE Connectivity | 0.13 @ Qty: 1000+ | |||
| Power and Signal Group | 640445-6 | 0.1702 | 1463.72 | 20000 | 1000 | TE Connectivity | 0.1702 @ Qty: 20000+ | |||
| TE Connectivity | 640445-6 | 0.1879 | 112.81516 | 1 | 22243 | TE Connectivity (TE) | 0.1879 @ Qty: 1000+ | |||
| Onlinecomponents.com | 640445-6 | 0.208 | 124.8832 | 1 | 45842 | TE Connectivity / AMP Brand | 0.208 @ Qty: 1000+ | |||
 | Newark | 06WX0409 | 0.232 | 140.128 | 10 | 19201 | AMP - TE CONNECTIVITY | 0.232 @ Qty: 1000+ | ||
| Future Electronics | 4319190 | 0.24 | 144.096 | 1 | 53537 | TE Connectivity | 0.24 @ Qty: 1000+ | |||
| Waldom | TE CONNECTIVITY AMP BRAND 640445-6 | 0.258 | 155.4 | 250 | 6389 | TE CONNECTIVITY/AMP BRAND | 0.222 @ Qty: 1200+ | |||
 | Zoro | G101037506 | 0.27 | 165.348 | 31 | 1000 | Te Connectivity | 0.27 @ Qty: 1000+ | ||
 | Digi-Key | 109099 | 0.315 | 189.126 | 1 | 104555 | TE Connectivity AMP Connectors | 0.315 @ Qty: 1000+ | ||
 | TME | 640445-6 | 0.452 | 271.3808 | 1 | 1000 | TE Connectivity | 0.452 @ Qty: 1000+ | ||
| us.rs-online.com | 70083693 | 0.55 | 331.1 | 5 | 1000 | TE Connectivity | 0.55 @ Qty: 1000+ | |||
| RS Delivers | 178-9596P | 0.5712 | 342.94848 | 1 | 1000 | TE Connectivity | 0.5712 @ Qty: 1000+ | |||
| AmazonTP | B0748LVRQR | 23.94 | 14373.576 | 1 | 1000 | 5 | TE CONNECTIVITY | 23.94 @ Qty: 1000+ |
