Amphenol GTC030AF18-19SW-025-B30

mpnGTC030AF18-19SW-025-B30
brandname: Amphenol
manufacturername: Amphenol

Amphenol Connector

Amphenol Connector

zoom

Brand: Amphenol
PartNumber: GTC030AF18-19SW-025-B30
Manufacturer: Amphenol
Label: Amphenol

Attributes

Key	Value
Amperage Rating	13A
Connector Style	Receptacle
Connector Type	Circular
Contact Material	Copper Alloy
Contact Mating Life	500
Contact Plating	Gold
Contact Size	10#16
Contact Style	Socket
Contacts Supplied	Yes
Contacts, # of	10
Crimp Wire Gauge	20,18,16
Endbell Type	Cable Clamp - Extended
Export Class	EAR / EAR99
Grommet & Seals Mat.	Neoprene
Insert Arrangement	18-19
Insert Material	Neoprene
Insert Rotation/Keying	W
Mounting Type	Wall - Rear Mount
Operating Temperature &.	-67 - +257 (-55 to +125)
Operating Voltage AC V .	500
Operating Voltage DC	700
Orientation	Straight
RoHS	Yes
Rotation Angle	80
Sealing	Unsealed
Service Rating	A
Shell Color	Black
Shell Material	Aluminum Alloy
Shell Plating	Black Anodize
Shielding	Yes
Termination Method	Crimp
Weight (g)	105.31160
Weight (lbs)	0.23220

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	PEI-Genesis	GTC030AF18-19SW-025-B30	58.36	1	95		Amphenol		58.36 @ 1
