MS3106E20-19P

mpnMS3106E20-19P
brandname: Amphenol Industrial Operations
manufacturername: Amphenol Industrial Operations

Amphenol MS3106E20-19P MIL-DTL-5015 (MS3100-MS3108) Circular Connectors

Amphenol MS3106E20-19P MIL-DTL-5015 (MS3100-MS3108) Circular Connectors

zoom

PartNumber: MS3106E20-19P
Manufacturer: Amphenol
Label: Amphenol

Attributes

Key	Value
Alternate Part No.	654-MS3106E20-19P
Applications	Marine, Military
Backshell Material, Pla.	Aluminum Alloy, Olive D.
Brand	Amphenol Industrial
Cable Opening	0.656" (16.66mm)
Color	Olive Drab
Connector Type	Plug, Male Pins
Contact Finish - Mating	Silver
Contact Finish Thicknes.	-
Contact Gender	Pin (Male)
Contact Material	Copper Alloy
Contact Plating	Silver
Current Rating	46 A
Current Rating (Amps)	-
Fastening Type	Threaded
Features	Backshell, Cable Clamp,.
Ingress Protection	Environment Resistant
Insert Arrangement	20-19
Insert Material	Neoprene
Manufacturer	Amphenol
Manufacturer Part No.	MS3106E20-19P
Material Flammability R.	-
Mfr	Amphenol Industrial Ope.
MIL Type	MIL-DTL-5015
Mounting Angle	Straight
Mounting Feature	-
Mounting Style	Free Hanging
Mounting Type	Free Hanging (In-Line)
Number of Positions	3
Operating Temperature	-55?C ~ 125?C
Orientation	N (Normal)
Part # Aliases	MS31O6E20-19P
Part Status	Active
Product Category	Circular MIL Spec Conne.
Product Type	Plugs
Series	MS 5015
Shell Finish	Olive Drab Chromate ove.
Shell Material	Aluminum Alloy
Shell Plating	Olive Drab Chromate ove.
Shell Size	20
Shell Size - Insert	20-19
Shell Size, MIL	-
Shell Style	In-Line
Shielding	Unshielded
Termination	Solder Cup
Termination Style	Solder
Tradename	5015
Voltage Rating	700 V, -
Wire Gauge	8-10

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	AmazonTP	B00B0601A2	40.6	1	In Stock	2	Amphenol Corporation (AMP)		40.6 @ 1
	Newark	76J3527	50.12	1	6		AMPHENOL INDUSTRIAL		50.12 @ 1
	Hotenda	H1146166	50.93	1	In Stock		Amphenol Industrial		50.93 @ 1
	Digi-Key	AMS3106E20-19P-ND	55.18	1	In Stock		Amphenol Industrial Operations		55.18 @ 1
	RS Delivers	200-4785	66.504	1	In Stock		Amphenol Industrial		66.504 @ 1
	swatee.com	MS3106E20-19P	97.52	1	4		Amphenol		97.52 @ 1
