- mpn000-68175-5RFX
- brandname: Amphenol RF
- manufacturername: Amphenol RF
CONN,RF/COAXIAL,BNC STR PLUG,5 CRIMP-Crimp,50 OHM,4-RG59/ CBL
- Brand: Amphenol RF
- PartNumber: 68175-5RFX
- PackageQuantity: 3
- Manufacturer: AMPHENOL RF
- Label: AMPHENOL RF
Attributes
| Key | Value |
|---|
| Alternate Part No. | 523-68175-5RFX |
| Angle | Straight |
| Application | Commercial |
| Body Finish | Nickel |
| Body Material | Brass |
| Body Style | Straight |
| Brand | Amphenol RF |
| Cable Group | RG-59, Belden 1426A, 15. |
| Cable Type | RG-59, Belden 1505A, Be. |
| Category | Connectors, Interconnec. |
| Center Contact Material | Brass |
| Center Contact Plating | Gold |
| connector gender | m |
| Connector Style | BNC |
| Connector Type | Plug, Male Pin |
| Contact Material | Brass |
| Contact Plating | Gold |
| Contact Termination | Crimp |
| Coupling Mechanism | Bayonet |
| Dielectric Material | Tetrafluoroethylene, Po. |
| Fastening Type | Bayonet Lock |
| Features | - |
| Frequency - Max | 4 GHz |
| Gender | Plug |
| Housing Color | Silver |
| Housing Finish | Nickel |
| Housing Material | Brass |
| Impedance | 50Ohm, 50 Ohms |
| Includes | 3 pcs - 1 Connector, 1 . |
| Ingress Protection | - |
| Insertion Loss | 0.2dB |
| Insulation Resistance | 5000 MOhms |
| item per pack | 1 |
| Manufacturer | Amphenol |
| Manufacturer Part No. | 68175-5RFX |
| Mating Cycles | 500 |
| Mating Type | Bayonet |
| Maximum Frequency | 4 GHz |
| Mfr | Amphenol RF |
| Mounting Feature | - |
| mounting type | inline |
| Mounting Type | Free Hanging (In-Line) |
| number of contacts | 1 |
| Number of Ports | 1 |
| Operating Temperature | -65 to +165 ?C, -65?C ~. |
| Operating Temperature R. | - 65 C to + 165 C |
| Orientation | Straight |
| package | Bulk |
| Package | Bulk |
| Part # Aliases | 000-68175-5RFX |
| Part Status | Active |
| Polarity | Standard |
| Primary Type | BNC |
| Product | Connectors |
| Product Category | RF Connectors / Coaxial. |
| RF Series | BNC |
| Series | BNC, BNC Series, - |
| Shield Termination | Crimp |
| Special Features | 3Pc |
| Termination | Crimp |
| Termination Style | Cable - Crimp |
| Type | Cable Plug |
| Voltage Rating | 335 V, 500 V |
