| Alarm/Audio | 1 input, 1 output / 1 input (RCA), 1 output (RCA) |
| Angle Adjustment | Any Angle |
| Backlight Compensation (BLC) | Off/On (5 Zone) |
| Day and Night | IR cut filter with auto switch (Day/Night/Auto/Schedule) |
| Digital NR | Yes (3D DNR) |
| Dimensions | 11.79" x 4.25" (299.5mm x 108.0mm) |
| Ethernet | 1 x RJ45 10M / 100M Ethernet Port |
| Field of View | Horizontal: 101 ~ 32?, Vertical: 71 ~ 23?, Diagonal: 129 ~ 40? |
| Flip / Mirror | Flip/Rotation |
| Gain Control | Auto |
| Hardware Reset, Image Setting, Sharpness, True WDR | Yes |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Image Size | 2592 x 1944 |
| Ingress Protection | IP67 |
| Input Voltage | DC 12V / PoE (802.3af) |
| IR Distance | Up to 98ft. (30m) |
| Language | Support for English and Korean |
| Lens | Motorized 2.7 - 13.5 mm |
| Main Stream | 2592 x 1944, 1920 x 1080, 1280 x 720 |
| Max. Framerate | 50Hz: 25fps at5MP/4MP/3MP/2MP/960P/720P/VGA/QVGA, 60Hz: 30fps at5MP/4MP/3MP/2MP/960P/720P/VGA/QVGA |
| Max. Image Resolution | 2592 x 1944 at 30fps |
| Min. Illumination | Color: 0.05lux at F1.2(AGC ON) BW: 0lux w IR ON |
| Mobile Stream | VGA(640x480), QVGA(320x240) |
| Motion Detection | Off/On (8 Level) |
| On-Board Storage | Micro SD slot, up to 256GB |
| ONVIF | ONVIF Profile S / G |
| Power Consumption | ?6W |
| Privacy Mask | Off/On (4 Zone, Rectangle) |
| Protocol | HTTP, HTTPs, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, PPPoE, DHCP |
| Resolution | 5MP |
| Security | IP Address Filter; Complicated Password; Authenticated Username and Password |
| Shutter Speed | 1/20,000s ~ 1/5s |
| Slow Shutter | Supported |
| Sub Stream | 720P(1280x720), VGA(640x480), QVGA(320x240) |
| Supported Resolutions | 2592 x 1944, 1920 x 1080, 1280 x 720, 640 x 480, 320 x 240 |
| Video Bit Rate | 8 Kbps ~ 8 Mbps (CBR / VBR Adjustable) |
| Video Compression | H.265 / H.264 |
| WDR | 120dB |
| Weight | 0.7lbs |
| White Balance | Auto/Manual/Indoor |
| Working Temperature | -22?~131? F (-30?~55? Celcius) |
