mpn:
brand:
manufacturer:
MPN:
Description:
Product Type: Three PhaseHP: 20RPM: 1765Volts: 230/460Amps: 24/48Hz: 60Phase: 3Frame: 256TCEnclosure Type: TEFC (Totally Enclosed Fan Cooled)Enclosure Material: Stainless SteelMounting: C-Face/RigidShaft Diameter: 1.625"Overall Length: 25.18"Rotation: ReversibleNumber of Speeds: 1Service Factor: 1.00Bearings: SealedEff
Attributes
| Key ^ | Value |
|---|---|
| Amps | 24/48 |
| Bearings | Sealed |
| Duty Cycle | Continuous |
| Efficiency | 93.0% |
| Enclosure Material | Stainless Steel |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Frame | 256TC |
| HP | 20 |
| Hz | 60 |
| Insulation Class | H |
| Inverter Duty | Yes |
| Manufacturer Model # | 39E646Y400G2 |
| Maximum Ambient Temperature | 40? C |
| Mounting | C-Face/Rigid |
| Number of Speeds | 1 |
| Overall Length | 25.18" |
| Phase | 3 |
| Product Type | Three Phase |
| Rotation | Reversible |
| RPM | 1765 |
| Service Factor | 1.00 |
| Shaft Diameter | 1.625" |
| Ship Weight | 290 lbs. |
| Volts | 230/460 |
