mpn:
brand:
manufacturer:
MPN:
Description:
Product Type: Three PhaseHP: 15RPM: 1800Volts: 460Amps: 15Phase: 3Frame: 254TEnclosure Type: IP54Enclosure Material: LaminatedMounting: RigidShaft Diameter: 1.625"Overall Length: 23.89"Rotation: ReversibleService Factor: 1.15Bearings: BallThermal Protection: Normally Closed ThermostatInsulation Class: HDuty Cycle: Cont
Attributes
| Key ^ | Value |
|---|---|
| Amps, HP | 15 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Enclosure Material | Laminated |
| Enclosure Type | IP54 |
| Frame | 254T |
| Insulation Class | H |
| Manufacturer Model # | H25-A000-0001 |
| Mounting | Rigid |
| Overall Length | 23.89" |
| Phase | 3 |
| Product Type | Three Phase |
| Rotation | Reversible |
| RPM | 1800 |
| Service Factor | 1.15 |
| Shaft Diameter | 1.625" |
| Ship Weight | 210 lbs. |
| Thermal Protection | Normally Closed Thermostat |
| Volts | 460 |
