Description:
The Definite Purpose family of motors captures a host of variety demanded by the marketplace. These motors include TEFC and ODP Two-speed motors, as well as single phase Pressure Washer motors. This group of specialty motors includes Arbor Saw to Woodworking, Pre-1952 NEMA motors to SAE Hydraulic Pump motors. An extensive line of TEFC and ODP F-2 motors are available as well in 1 Hp through 60 Hp. The Automotive Approved motors, approved by major US automobile manufacturers, are available in cast iron designs and meet all requirements for sound power levels. A broad line of Design D Oil Field Pump motors, requiring high torque and high slip, are available in 3 Hp through 150 Hp.<br><br><b>Features</b><ul style=Margin-top:0px;padding-top: 5px: padding-bottom: 5px;><li>Heavy gauge steel and cast iron frames</li><li>Ball bearings</li><li>ISR? (Inverter Spike Resistant?) copper windings</li><li>Low-loss electrical grade lamination steel</li><li>Three year warranty</li></ul><b>Application(s)</b><ul style=Margin-top:0px;padding-top: 5px: padding-bottom: 5px;><li>Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and constant torque speed range with properly sized and adjusted variable frequency drives.</li></ul>
Weight:
73.0
Weight:
73.0 LB
Preferred Price:
1109.01
Price:
1109.01
Min Simple Price:
626.56
Absolute Min Price:
889.71
Min Price:
889.71
Dimensions:
[19.0, 14.0, 13.0]
qty:
21
simpleSku:
Mzg5Nw:::EFM3611T
sku:
Mzg5Nw::6D:EFM3611T@y0
condition:
11
seller:
electricmotorwholesale.com
amzMan:
baldor electric
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Amps | 4.2/8.4/9 |
| Application, Product Type | General Purpose |
| Bearings | Ball |
| Comments, Frequency | 60 Hz |
| Drive End Flange Type | Standard |
| Duty Cycle | Continuous |
| Efficiency | 89.5% |
| Efficiency % | 89.5 % |
| Enclosure | Totally Enclosed Fan Cooled |
| Enclosure Material, Motor Frame Material | Steel |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Enclosure, Enclosure Type | TEFC |
| Estimated Weight | 73.00 |
| Family Name | Three Phase Enclosed Family |
| Family Series | Baldor Motors |
| FL Amps | 9-8.4/4.2 |
| FL Efficiency | 89.5 |
| Frame, NEMA Frame | 182T |
| Gross Weight, Net Weight | 0 lbs |
| Hertz, Hz | 60 |
| Horsepower | 3 hp |
| HP, Phase | 3 |
| Includes | Conduit Box |
| Insulation Class | F |
| Inverter Duty | Yes |
| Item | General Purpose Motor |
| Item Number, Manufacturer Part Number, Part Number | EFM3611T |
| Length Less Shaft | 13 13/16 in |
| Manufacturer | Baldor, Baldor Reliance |
| Manufacturer Model # | 36A006S266G1 |
| Manufacturers Warranty Length | 3 yr |
| Maximum Ambient Temperature | 40? C |
| Motor Application | General Application |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor, Service Factor | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Mounting | Rigid |
| Mounting Type | Footed |
| Mounting, Mounting Type | Foot Mount |
| Nameplate RPM | 1,760 |
| Nominal Voltage, Voltage (AC) | 208 VAC |
| Number of Speeds | 1 |
| Overall Length | 16.55", 16 9/16 in |
| Phase | 3 Phase |
| Product Type | Three Phase |
| Rotation | Reversible |
| RPM | 1760 RPM, 1,760 RPM |
| RPM Range | 1,701-1,800 |
| RPM, Speed (RPM) | 1760 |
| Series | GE3 Series |
| Shaft Dia. | 1 1/8 in |
| Shaft Diameter | 1.125" |
| Shaft Length | 2 3/4 in |
| Ship Weight | 73 lbs. |
| Standards | CSA, CSA EEV, UR |
| UPC Code | 781568543337 |
| Voltage | 208-230/460V AC, 208V, 230V, 460V |
| Voltage Compatibility | 200-230/440V AC, 200-230/460V AC, 208-230/460V AC, 460V AC |
| Volts | 230/460 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | electricmotorwholesale.com | EFM3611T | 626.56 | 626.56 | 1 | In Stock | Baldor | 626.56 @ Qty: 1+ | ||
 | emotorpro.com | EFM3611T | 833.8 | 833.8 | 1 | In Stock | Baldor | 73.0 | 833.8 @ Qty: 1+ | |
| factorysupplyoutlet.com | UF88DJ | 913.37 | 913.37 | 1 | In Stock | Baldor-Reliance | 913.37 @ Qty: 1+ | |||
 | Galco | EFM3611T-BLDR | 916.49 | 916.49 | 1 | In Stock | Baldor | 916.49 @ Qty: 1+ | ||
 | Walker Industrial | EFM3611T | 922.6 | 922.6 | 1 | In Stock | Baldor | 922.6 @ Qty: 1+ | ||
 | Global Industrial | WBB909553 | 925.0 | 925.0 | 1 | In Stock | 15 | Baldor-Reliance | 925.0 @ Qty: 1+ | |
 | Zoro | G8400034 | 928.99 | 928.99 | 1 | In Stock | Baldor-Reliance | 73.2 | 928.99 @ Qty: 1+ | |
| motorsandcontrol.com | EFM3611T | 961.04 | 961.04 | 1 | In Stock | Baldor Reliance | 73.0 | 961.04 @ Qty: 1+ | ||
 | apexindustrialautomation.com | EFM3611T | 1064.54 | 1064.54 | 1 | 1 | Baldor-Reliance | 1064.54 @ Qty: 1+ | ||
| us.rs-online.com | 71944049 | 1066.13 | 1066.13 | 1 | In Stock | Baldor-Reliance | 1066.13 @ Qty: 1+ | |||
 | pumpproducts.com | EFM3611T | 1092.67 | 1092.67 | 1 | In Stock | Baldor | 1092.67 @ Qty: 1+ | ||
 | cbtcompany.com | EFM3611T | 1093.28 | 1093.28 | 1 | In Stock | Baldor Reliance | 1093.28 @ Qty: 1+ | ||
| kirbyrisk.com | 3113474 | 1209.71 | 1209.71 | 1 | In Stock | Baldor | 1209.71 @ Qty: 1+ | |||
| motionindustries.com | 04553007 | 1330.37 | 1330.37 | 1 | In Stock | Baldor-Reliance | 1330.37 @ Qty: 1+ | |||
 | sustainablesupply.com | C2757404 | 1389.73 | 1389.73 | 1 | In Stock | Baldor Electric | 73.2 | 1389.73 @ Qty: 1+ | |
 | Raptor Supplies | AJ6RRM | 1493.4388365 | 1493.4388365 | 1 | In Stock | BALDOR MOTOR | 1493.4388365 @ Qty: 1+ |
