mpn:
brand:
manufacturer:
MPN:
Description:
Some applications require NEMA motors which operate on true 50 Hz power. Where this 50 Hz power is all that is available, these NEMA motors are designed to be used at rated voltages with tolerance of ? 15% on voltage.<br><br><b>Features</b><ul style=margin-top:0px;padding-top: 5px: padding-bottom: 5px;><li>Windings tied each end at every slot for rigidity</li><li>Ball bearings</li><li>High temperature insulation</li><li>Copper windings</li></ul><b>Application(s)</b><ul style=margin-top:0px;padding-top: 5px: padding-bottom: 5px;><li> Suitable for a wide variety of applications where only 50 hertz power is available. Motors are designed to be used at rated voltages with tolerance of ? 15% on voltage.</li></ul><br><br>
Weight:
2.1875
Weight:
35.0 LB
Preferred Price:
790.34
Price:
790.34
Min Simple Price:
446.52
Absolute Min Price:
634.04
Min Price:
634.04
Dimensions:
[12.0, 1.0, 1.0]
qty:
21
simpleSku:
Mzg5Nw:::L1309-50
sku:
Mzg5Nw::UA:L1309-50@y0
condition:
11
seller:
emotorpro.com
amzMan:
baldor
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Amps | 6.0/12.0 |
| Bearing Type, Bearings | Ball |
| Comments | Wound for 50 Hertz Service |
| Composition, Enclosure Material | Steel |
| Drive End Flange Type | Standard |
| Duty Cycle | Continuous |
| Efficiency | 66.0% |
| Efficiency % | 65 % |
| Enclosure | Drip Proof |
| Enclosure, Enclosure Type | Open |
| Estimated Weight | 34.00 |
| Family Series | Baldor Motors, L Series |
| FL Amps | 12/6 |
| FL Efficiency | 66 |
| Frame, NEMA Frame | 56 |
| Gross Weight, Net Weight | 35 lbs |
| Hertz, Hz | 50 |
| Horsepower | 1 hp |
| HP, Number of Speeds, Phase | 1 |
| Insulation Class | B |
| Inverter Duty | No |
| Item Number, Manufacturer Part Number, Part Number | L1309-50 |
| Manufacturer | Baldor, Baldor Reliance |
| Manufacturer Model # | 34F17W655 |
| Maximum Ambient Temperature | 40? C |
| Mounting | Foot Mount, Rigid |
| Mounting Type | Foot Mount, Rigid |
| Nominal Voltage | 120 VAC, 208 VAC, 240 VAC |
| Overall Length | 11.01 ", 11.51" |
| Overload Protection | None |
| Product Series | L |
| Product Type | General Purpose |
| Rotation | Reversible |
| RPM | 3,600 RPM |
| RPM, Speed (RPM) | 2850 |
| Service Factor | 1.25 |
| Shaft Diameter | 0.625" |
| Ship Weight | 34 lbs. |
| Voltage | 110-120V, 220V |
| Voltage (AC) | 115 VAC, 230 VAC |
| Volts | 110/220 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | emotorpro.com | L1309-50 | 446.52 | 446.52 | 1 | In Stock | Baldor | 34.0 | 446.52 @ Qty: 1+ | |
| factorysupplyoutlet.com | KE74ML | 489.14 | 489.14 | 1 | In Stock | Baldor-Reliance | 489.14 @ Qty: 1+ | |||
 | Walker Industrial | L1309-50 | 494.08 | 494.08 | 1 | In Stock | Baldor | 494.08 @ Qty: 1+ | ||
 | Galco | L1309-50-BLDR | 494.08 | 494.08 | 1 | In Stock | Baldor | 35.0 | 494.08 @ Qty: 1+ | |
 | Global Industrial | WBB909667 | 506.0 | 506.0 | 1 | In Stock | 15 | Baldor-Reliance | 506.0 @ Qty: 1+ | |
| motorsandcontrol.com | L1309-50 | 514.66 | 514.66 | 1 | In Stock | Baldor Reliance | 34.0 | 514.66 @ Qty: 1+ | ||
| us.rs-online.com | 72514645 | 552.14 | 552.14 | 1 | In Stock | Baldor-Reliance | 552.14 @ Qty: 1+ | |||
 | apexindustrialautomation.com | L1309-50 | 570.09 | 570.09 | 1 | In Stock | Baldor-Reliance | 570.09 @ Qty: 1+ | ||
 | pumpproducts.com | L1309-50 | 575.67 | 575.67 | 1 | In Stock | Baldor | 575.67 @ Qty: 1+ | ||
 | cbtcompany.com | L1309-50 | 585.48 | 585.48 | 1 | In Stock | Baldor Reliance | 585.48 @ Qty: 1+ | ||
 | Raptor Supplies | AJ6WWN | 1447.0688115 | 1447.0688115 | 1 | In Stock | BALDOR MOTOR | 1447.0688115 @ Qty: 1+ |
