mpn:
brand:
manufacturer:
MPN:
Description:
Some applications require NEMA motors which operate on true 50 Hz power. Where this 50 Hz power is all that is available, these NEMA motors are designed to be used at rated voltages with tolerance of ? 15% on voltage.<br><br><br><br>
Weight:
26.0
Weight:
1.625 LB
Preferred Price:
555.74
Price:
555.74
Min Simple Price:
313.98
Absolute Min Price:
445.85
Min Price:
445.85
Dimensions:
[12.0, 1.0, 1.0]
qty:
21
simpleSku:
ODcyMg:::M3538-57
sku:
ODcyMg::12:M3538-57@y0
condition:
11
seller:
electricmotorwholesale.com
amzMan:
baldor
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Amps, FL Amps | 1.7/1 |
| Application, Product Type | General Purpose |
| Bearings | Ball |
| Comments | 50 hz |
| Composition, Enclosure Material | Steel |
| Construction | Rolled Steel |
| Country of Origin (subject to change) | United States |
| Drive End Flange Type | Standard |
| Duty Cycle | Continuous |
| Efficiency | 73.0% |
| Efficiency % | 73 % |
| Enclosure | Totally Enclosed Fan Cooled |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Enclosure, Enclosure Type | TEFC |
| Estimated Weight | 26.00 |
| Family Name | Three Phase Enclosed Family |
| Family Series | Baldor Motors |
| FL Efficiency | 73 |
| Frame, NEMA Frame | 56 |
| Gross Weight, Net Weight | 0 lbs |
| Hertz, Hz | 50 |
| Horsepower | 1/2 hp |
| HP | 0.5, 1/2 |
| Insulation Class | B |
| Item Number, Manufacturer Part Number, Part Number | M3538-57 |
| Manufacturer | Baldor, Baldor Reliance |
| Manufacturer Model # | 34A061X268G1 |
| Maximum Ambient Temperature | 40? C |
| Mounting | Rigid |
| Mounting Type | Footed |
| Mounting, Mounting Type | Foot Mount |
| Nominal Voltage | 208 VAC, 240 VAC |
| Number of Speeds | 1 |
| Overall Length | 11.35" |
| Phase | 3, 3 Phase |
| Product Type | Three Phase |
| Rotation | Reversible |
| RPM | 1,425 RPM, 1425 RPM |
| RPM, Speed (RPM) | 1425 |
| Series | GE3 Series |
| Service Factor | 1.25 |
| Shaft Diameter | 0.625" |
| Ship Weight | 26 lbs. |
| UPC Code | 781568656662 |
| Voltage | 230V, 400V |
| Voltage (AC) | 230 VAC |
| Volts | 230/400 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | electricmotorwholesale.com | M3538-57 | 313.98 | 313.98 | 1 | In Stock | BALDOR | 313.98 @ Qty: 1+ | ||
| AmazonTP | B07FN514V4 | 361.81 | 361.81 | 1 | In Stock | 3 | Baldor Electric | 361.81 @ Qty: 1+ | ||
 | emotorpro.com | M3538-57 | 417.47 | 417.47 | 1 | In Stock | Baldor | 26.0 | 417.47 @ Qty: 1+ | |
| factorysupplyoutlet.com | UC32NX | 457.31 | 457.31 | 1 | In Stock | Baldor-Reliance | 457.31 @ Qty: 1+ | |||
 | Galco | M3538-57-BLDR | 461.93 | 461.93 | 1 | In Stock | Baldor | 461.93 @ Qty: 1+ | ||
 | Walker Industrial | M3538-57 | 461.93 | 461.93 | 1 | In Stock | Baldor | 461.93 @ Qty: 1+ | ||
 | Global Industrial | WBB909599 | 462.95 | 462.95 | 1 | In Stock | Baldor-Reliance | 462.95 @ Qty: 1+ | ||
| motorsandcontrol.com | M3538-57 | 481.18 | 481.18 | 1 | In Stock | Baldor Reliance | 26.0 | 481.18 @ Qty: 1+ | ||
 | standardelectricsupply.com | 2301442 | 500.66 | 500.66 | 1 | In Stock | Baldor Electric | 500.66 @ Qty: 1+ | ||
 | apexindustrialautomation.com | M3538-57 | 533.0 | 533.0 | 1 | 2 | Baldor-Reliance | 533.0 @ Qty: 1+ | ||
 | cbtcompany.com | M3538-57 | 547.39 | 547.39 | 1 | In Stock | Baldor Reliance | 547.39 @ Qty: 1+ | ||
 | pumpproducts.com | M3538-57 | 548.17 | 548.17 | 1 | In Stock | Baldor | 548.17 @ Qty: 1+ | ||
 | Zoro | G3290352 | 556.25 | 556.25 | 1 | In Stock | Baldor-Reliance | 556.25 @ Qty: 1+ | ||
| us.rs-online.com | 71944314 | 577.4 | 577.4 | 1 | In Stock | Baldor-Reliance | 577.4 @ Qty: 1+ | |||
| motionindustries.com | 06600487 | 620.52 | 620.52 | 1 | In Stock | Baldor-Reliance | 620.52 @ Qty: 1+ | |||
 | Raptor Supplies | AJ6XHX | 1375.8489225 | 1375.8489225 | 1 | In Stock | BALDOR MOTOR | 1375.8489225 @ Qty: 1+ |
