mpn:
brand:
manufacturer:
MPN:
Weight:
1.25
Weight:
20.0 LB
Preferred Price:
674.28
Price:
674.28
Min Simple Price:
381.17
Absolute Min Price:
540.88
Min Price:
540.88
Dimensions:
[12.0, 1.0, 1.0]
qty:
21
simpleSku:
Mzg5Nw:::PSC3413A
sku:
Mzg5Nw::B4:PSC3413A@y0
condition:
11
seller:
emotorpro.com
amzMan:
baldor
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Amps | 1.3/2.6 |
| Application | Farm Duty |
| Bearings | Ball |
| Comments, Frequency, Motor Frequency | 60 Hz |
| Composition, Construction | Cast Iron |
| Country of Origin (subject to change) | United States |
| Drive End Flange Type | Standard |
| Duty Cycle | Continuous |
| Efficiency | 65.5% |
| Efficiency % | 65.5 % |
| Enclosure Material, Motor Construction | Steel |
| Enclosure Type | TEAO (Totally Enclosed Air Over) |
| Enclosure, Enclosure Type | TEAO |
| Enclosure, Motor Enclosure Type | Totally Enclosed Air Over |
| Estimated Weight | 19.00 |
| Family Series | Baldor Motors |
| FL Amps | 2.6/1.3 |
| FL Efficiency | 65.5 |
| Frame, Frame Type, Motor Frame Model | 48Z |
| Gross Weight, Net Weight | 20 lbs |
| Hertz, Hz | 60 |
| Horsepower | 1/4 hp |
| Horsepower Rating, Motor Horsepower | 0.25 HP |
| HP | 0.25, 1/4 |
| Insulation Class | B |
| Item Number, Manufacturer Part Number, Part Number | PSC3413A |
| Manufacturer | Baldor-Reliance, Baldor, Baldor Reliance |
| Manufacturer Model # | 34G144W427 |
| Maximum Ambient Temperature | 40? C |
| Motor Amperage (Full Load) | 2.600 Amp, 1.300 Amp |
| Motor Insulation Class | Class B Insulation |
| Motor Nema Design | Nema Design C |
| Motor RPM's | 1800 RPM |
| Motor Voltage | 115 Volt, 230 Volt |
| Motor Voltage Phases, Phase | 1 Phase |
| Mounting | Rigid |
| Mounting Type | Footed |
| Mounting, Mounting Type | Foot Mount |
| Nominal Voltage | 120 VAC |
| Number of Speeds, Phase, Service Factor | 1 |
| Overall Length | 11.34" |
| Product Type | Fractional HP (HVAC) |
| Rotation | Reversible |
| RPM | 1,625 RPM, 1625 RPM |
| RPM, Speed (RPM) | 1625 |
| Series | HV3 Series |
| Service Factor | 1.00 |
| Shaft Diameter | 0.5" |
| Ship Weight | 19 lbs. |
| Special Features | Automatic Thermal Overload |
| Supply Voltage | 115/230 VAC |
| Thermal Protection | Automatic |
| UPC Code | 781568148655 |
| Voltage | 110-120V, 230V |
| Voltage (AC) | 110-120 VAC |
| Volts | 115/230 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | emotorpro.com | PSC3413A | 381.17 | 381.17 | 1 | In Stock | Baldor | 19.0 | 381.17 @ Qty: 1+ | |
 | midwestapplianceparts.com | PSC3413A-BM-P | 410.07 | 410.07 | 1 | In Stock | Baldor | 410.07 @ Qty: 1+ | ||
 | Walker Industrial | PSC3413A | 414.73 | 414.73 | 1 | In Stock | Baldor | 414.73 @ Qty: 1+ | ||
| factorysupplyoutlet.com | RK40KV | 417.54 | 417.54 | 1 | In Stock | Baldor-Reliance | 417.54 @ Qty: 1+ | |||
 | Galco | PSC3413A-BLDR | 421.76 | 421.76 | 1 | In Stock | Baldor | 20.0 | 421.76 @ Qty: 1+ | |
 | Global Industrial | WBB390961 | 423.95 | 423.95 | 1 | In Stock | 20 | Baldor-Reliance | 423.95 @ Qty: 1+ | |
| motorsandcontrol.com | PSC3413A | 439.33 | 439.33 | 1 | In Stock | Baldor Reliance | 19.0 | 439.33 @ Qty: 1+ | ||
 | apexindustrialautomation.com | PSC3413A | 486.65 | 486.65 | 1 | 32 | Baldor-Reliance | 486.65 @ Qty: 1+ | ||
 | pumpproducts.com | PSC3413A | 491.33 | 491.33 | 1 | In Stock | Baldor | 491.33 @ Qty: 1+ | ||
 | cbtcompany.com | PSC3413A | 499.79 | 499.79 | 1 | In Stock | Baldor Reliance | 499.79 @ Qty: 1+ | ||
 | Zoro | G5523486 | 507.5 | 507.5 | 1 | In Stock | Baldor-Reliance | 507.5 @ Qty: 1+ | ||
| rspsupply.com | BALDOR PSC3413A | 509.95 | 509.95 | 1 | In Stock | Baldor | 509.95 @ Qty: 1+ | |||
| us.rs-online.com | 71934456 | 518.41 | 518.41 | 1 | In Stock | Baldor-Reliance | 518.41 @ Qty: 1+ | |||
| kirbyrisk.com | 2600801 | 553.01 | 553.01 | 1 | In Stock | Baldor | 553.01 @ Qty: 1+ | |||
 | motionindustries.com | 00544438 | 597.92 | 597.92 | 1 | In Stock | Baldor-Reliance | 597.92 @ Qty: 1+ | ||
 | Raptor Supplies | AJ6XYC | 1235.2639455 | 1235.2639455 | 1 | In Stock | BALDOR MOTOR | 1235.2639455 @ Qty: 1+ |
