| Agency | RoHS |
| Environmental Operation Range | 32 to 122 F (0 to 50 C) 0 to 95%, non-condensing |
| Field Calibration Adjustment | +-5% in 0.1% increments (Factory Calibrated) |
| Humidity | Capacitive Polymer, +-2%RH at 25?C (77?F), 20 to 80%RH |
| Material and Rating | ABS Plastic, UL 94, V-0 |
| Mounting | Standard 2"x4" junction box, European junction box or drywall mount (screws provided) box or drywall mount (screws provided) |
| Optional Passive Temperature Sensor Accuracy | No Sensor |
| Power | 15 to 35 VDC for 0 to 10 VDC Output |
| Power Consumption | 4 mA max. for 0 to 5 VDC and 0 to 10 VDC Output |
| Temp | Semi-conductor Band Gap, +-0.3?C (+-0.54?F) at 20 to 40?C (68 to 104?F) |
| Temp / %RH Sensor Construction | Communicating Integrated Circuit |
| Wiring | 2 to 5 pair of 16 to 22 AWG |
