| Applications | ITE (Commercial) |
| Approval Agency | CE, CSA, UL |
| Base Product Number | HCBB-75 |
| Case Type | CBB |
| Category | Power Supplies - External/Internal (Off-Board) |
| Configuration | Open Frame |
| Current - Output 1 | 6 A |
| Current - Output 2, Current - Output 3 | 1.5 A |
| Dimensions | 11.00 L x 4.87 W x 3.28 D in |
| Efficiency | 45% |
| Features | Adjustable Output, Remote Sense |
| Input Frequency | 47 to 63 Hz |
| Input Voltage | 100 VAC ; 110 VAC ; 115 VAC ; 120 VAC ; 127 VAC ; 190 VAC ; 200 VAC ; 220 VAC ; 230 VAC ; 240 VAC |
| Input Voltage Range | 100-264 VAC |
| Line Regulation, Load Regulation | ?0.05% |
| Mfr | Bel Power Solutions |
| Minimum Load Required, Voltage - Output 4, Voltage - Output 5, Voltage - Output 6 | - |
| Mounting Type | Panel Mount, Chassis Mount |
| Number of Outputs | 3 |
| Operating Temperature | 0 ?C, 0?C ~ 50?C |
| Operation, Type | Linear |
| Output 1 Voltage | 5 VDC |
| Output 2 Voltage | 12 VDC |
| Output 3 Voltage | -5 VDC |
| Output Current | 6A@5V, 1.7A@12V, 0.7A@-5V |
| Output Power | 54 W |
| Output Type | Triple Output |
| Output Voltage | 5 VDC, 12 VDC, -5 VDC |
| Package | Bulk |
| Power (Watts) | 75W |
| Primary Type | AC-DC |
| Product Header | Linear Power Supply |
| Product Status | Active |
| Response Time | 50 us (Max.) |
| Series | Linear Series, Linear CBB |
| Size / Dimension | 11.00" L x 4.87" W x 3.28" H (279.4mm x 123.7mm x 83.3mm) |
| Special Features | Remote Sense |
| Standard Number | 60950-1; 62368-1 |
| Standards | UL Listed, CSA Certified, CE Marked and T?V Approved |
| Type | Embedded |
| Voltage - Input | 100, 120, 220, 230, 240 VAC |
| Voltage - Isolation | 4.242 kV |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | 15V |
| Voltage - Output 3 | -15V |
