Belden 9423 060500

B005T947UQ

Belden / CDT - 9423 060500 - 22-9c Str Tnc Pvc Pvc Jkt Cmg 150v 80c Rohs

Belden / CDT - 9423 060500 - 22-9c Str Tnc Pvc Pvc Jkt Cmg 150v 80c Rohszoom

Attributes

Key Value
ApplicationFor computers, communic.
Base Product Number9423
Cable TypeMulti-Conductor, Comput.
CategoryCables, Wires
Conductor InsulationPoly-Vinyl Chloride (PV.
Conductor MaterialTinned Copper (TC), Cop.
Conductor Strand7/30
ConfigurationConductors
Country of Origin (subj.Unknown
Features-
Insulation MaterialPolyvinyl Chloride (PVC)
Jacket (Insulation) Dia.0.244" (6.20mm)
Jacket (Insulation) Mat.Poly-Vinyl Chloride (PV.
Jacket (Insulation) Thi.0.0320" (0.813mm)
Jacket ColorChrome
Jacket MaterialPolyvinyl Chloride (PVC)
Length500.0' (152.4m), 500 ft
MfrBelden Inc.
Number of Conductors9
Operating Temperature-20?C ~ 80?C
Outer Diameter0.244 in.
PackageSpool
PackagingCoil
Part StatusActive
Product HeaderUnshielded Non-Plenum M.
RatingsUL Style 2576
SeriesClassics, 9423 Series
Shield Coverage-
Shield Material-
Shield Type-
StandardsUL AWM Style 2576 ; NEC.
Stranding7x30
Temperature, Rating-20 to 80 C
UsageAudio, Control, Instrum.
Wire Gauge22 AWG
Wire Size22 AWG

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomalldataresource.comB9423-5004.27123Belden4.27 @ 1
AmazonTPB005T947UQ695.0212310Belden695.02 @ 1
Digi-Key81312491320.01123Belden Inc.1320.01 @ 1
us.rs-online.com700050531550.6213Belden1550.62 @ 1
thumbzoomNewark19C54241596.511In StockBELDEN1596.51 @ 1
thumbzoomZoroG11572841669.1112330Belden1669.11 @ 1
