Attributes
| Key ^ | Value |
|---|---|
| Brand | Bourns |
| Depth | 13.25mm |
| Dimensions | 27.94 x 13.25 x 12.5mm |
| Electrical Taper | Electrical Taper |
| Height | 12.5mm |
| Length | 27.94mm |
| Maximum Operating Temperature | +125?C |
| Maximum Resistance | 5k? |
| Minimum Operating Temperature | +1?C |
| Mounting Hole Diameter | Mounting Hole Diameter |
| Mounting Type | Bushing Mount |
| Number of Turns | 1 |
| Potentiometer Type | Linear |
| Power Rating | Power Rating |
| Series | 53 |
| Shaft Diameter | 6.35 mm |
| Temperature Coefficient | ?150ppm/?C |
| Termination Style | Solder Lug |
| Tolerance | Tolerance |
