- mpnSRR1260-120M
- brandname: Bourns
- manufacturername: Bourns
BOURNS - SRR1260-120M - Power Inductor (SMD) 5.2 A 5 A 12.5mm x 12.5mm x 6mm Shielded SRR1260 Series 12181;H-6pack
- Brand: Bourns
- PartNumber: 4004129218
- Manufacturer: Bourns
- Label: Bourns
Attributes
| Key | Value |
|---|
| Base Product Number | SRR1260 |
| Category | Inductors, Coils, Chokes |
| Current - Saturation | 5A |
| Current - Saturation (I. | 5A |
| Current Rating | 5 A |
| Current Rating (Amps) | 5.2 A, 5.2A |
| DC Resistance (DCR) | 23mOhm Max, 23 mOhm Max |
| Description | FIXED IND 12UH 5.2A 23 . |
| Detailed Description | 12 ?H Shielded Drum Cor. |
| Digi-Key Part Number | SRR1260-120MTR-ND - Tap. |
| Frequency - Self Resona. | 19.4MHz |
| Height - Seated (Max) | 0.256" (6.50mm) |
| Inductance | 12 ?H, 12, 12 ?H |
| Inductance Frequency - . | 100kHz, 100 kHz |
| Lead Free Status / RoHS. | RoHS Compliant |
| Manufacturer | Bourns Inc. |
| Manufacturer Part Number | SRR1260-120M |
| Manufacturer Product Nu. | SRR1260-120M |
| Manufacturer Standard L. | 18 Weeks, 16 Weeks |
| Material - Core | Ferrite |
| Maximum Operating Tempe. | +125 ?C |
| Mfr | Bourns Inc. |
| Minimum Operating Tempe. | ?40 ?C |
| Mounting Type | Surface Mount |
| Operating Temperature | -40 to +125 ?C, -40, -4. |
| Package | Tape & Reel (TR) |
| Package / Case | Nonstandard |
| Packaging | Reel |
| Product Status | Active |
| Q @ Freq | 27 @ 2.52MHz |
| Ratings | - |
| Resistance DC | 0.023 Ohms |
| Self Resonant Frequency | 19.4 MHz |
| Series | SRR1 Series, SRR1260 |
| Shielding | Shielded |
| Size / Dimension | 0.492" L x 0.492" W (12. |
| Standard Package | 600 |
| Supplier Device Package | - |
| Termination | SMD |
| Tolerance | 0.2, ?20% |
| Type | Filter, Wirewound, Drum. |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Hotenda | H2163402 | 0.4464 | 600 | 224 | | Bourns, Inc. | | 0.4464 @ 600 |
| iodParts | SRR1260-120M | 0.478 | 600 | 600 | | Bourns | | 0.478 @ 600 |
 | Newark | 83R8949 | 0.59 | 600 | 169 | | BOURNS | | 0.59 @ 600 |
| us.rs-online.com | 70277059 | 0.66 | 600 | 600 | | Bourns | | 0.66 @ 600 |
| RS Delivers | 763-3531 | 0.8832 | 1 | 50 | | Bourns | | 0.8832 @ 1 |
| Arrow | SRR1260-120M | 0.957 | 1 | 360 | | Bourns | | 0.957 @ 1 |
 | Digi-Key | 1969955 | 1.416 | 1 | 20637 | | Bourns Inc. | | 1.416 @ 1 |
| AmazonSC | B00DEFCFO2 | 12.05 | 1 | 169 | | BOURNS | | 12.05 @ 1 |
