<p><strong>Features: </strong> </p> <ul><li><strong>Rugged Construction </strong> - Up to 6 mm / 0.25" thick top plate with heavy duty welded channel support </li> <li><strong>Legal for Trade </strong> - NTEP certified at 5,000 divisions </li> <li><strong>Low Profile </strong> - 91 cm / 3.1 inches high; 44 mm / 1.75" adjustable leveling feet </li> <li><strong>Finish </strong> - Powder coat paint </li> <li><strong>Versatile </strong> - Pit mounted or free standing </li> <li><strong>Load Cells </strong> - Four alloy tool steel potted </li> <li><strong>Mild Steel </strong> </li> </ul>
Attributes
| Key ^ | Value |
|---|---|
| Accuracy | NTEP at 5000 divisions, Class III |
| Capacity | 10,000 x 2 lb (5000 x 1 kg) |
| Certifications | NTEP COC #02-070 |
| Corner Protection | Closed corners to prevent damage to leveling feet while installing the scale |
| Dimension | 60 x 60 x 3.1 in, 152 x 152 x 7.9 cm |
| End Loading | 100% of rated capacity |
| Finish | Powder coat paint |
| J-Box Access | Top access for easy installation and service |
| J-Box Construction | Stainless steel |
| Leveling Feet | Four top access holes for a quick installation |
| Loadcell Material | Alloy tool steel potted |
| Loadcell Output Resistance | 350 ohm |
| Loadcell Rated Output | 3mv/V |
| Operating Temperature | -10? C to 40? C 14? F to 104? F |
| Overload Protection | 150% of rated capacity |
| Rated | IP65 |
| Threaded Eye Bolts | Two threaded top access eye-bolt holes for easy mobility and pit service |
