brand:
manufacturer:
Weight:
0.01
Weight:
0.01 LB
Price:
15.75
qty:
1
simpleSku:
NTAxNw:::YAV25L-2TC12E1-FX
sku:
NTAxNw::DM:YAV25L-2TC12E1-FX@y2
condition:
11
seller:
Megadepot
amzMan:
burndy
Dimensions:
[1.0, 1.0, 1.0]
Attributes
| Key | Value |
|---|---|
| Approvals | CSA, UL |
| Certification - CSA Approved | Yes |
| Certification - cULus | No |
| Certification - UL Recognized | No |
| Color | Pink |
| Color Code | Pink |
| Conductor - Copper DLO Size | 1/0 (275/#24) DLO |
| Conductor - Copper DLO Size Range | 1/0 (275/#24) DLO |
| Conductor - Copper Flex G Size | 1/0 AWG |
| Conductor - Copper Flex G Size Range | 1/0 AWG |
| Conductor - Copper Flex H Size | 1/0 AWG |
| Conductor - Copper Flex H Size Range | 1/0 AWG |
| Conductor - Copper Flex I Size | 1/0 AWG |
| Conductor - Copper Flex I Size Range | 1/0 AWG |
| Conductor - Copper Flex K Size | 1/0 AWG |
| Conductor - Copper Flex K Size Range | 1/0 AWG |
| Conductor - Copper Flex M Size | 1/0 AWG |
| Conductor - Copper Flex M Size Range | 1/0 AWG |
| Conductor - Copper Str Navy Size | 100 Navy |
| Conductor - Copper Str Navy Size Range | 100 Navy |
| Conductor - Copper Str Size | 1/0 |
| Conductor - Copper Str Size Range | 1/0 |
| Conductor - CopperWeld Str Size | 1/0 WELD |
| Conductor - CopperWeld Str Size Range | 1/0 WELD |
| Conductor - Material | Copper |
| Connector Type | Terminal |
| Die Index | 12 |
| Dimension - B Length fraction | 11/16 in |
| Dimension - B Length inch | 0.69 in |
| Dimension - Bolt Hole Size inch | 0.53 in |
| Dimension - Hole Size inch | 0.53 in |
| Dimension - Hole Size mm | 13 mm |
| Dimension - L Length Overall mm | 81 mm |
| Dimension - Length Overall inch | 3.20 in |
| Dimension - N inch | 0.53 in |
| Dimension - Outside Diameter inch | 0.56 in |
| Dimension - Pad Width inch | 0.83 in |
| Dimension - Strip Length inch | 11/16 |
| Dimension - Z inch | 0.56 in |
| Family Series | Burndy Terminals, YAV-L-2TC-FX Series |
| Feature - Barrel Type | Standard |
| Gross Weight | 0 lbs |
| Insulated | Non-Insulated |
| Item Number | YAV25L2TC12E1FX |
| Manufacturer | Burndy |
| Manufacturer Part Number | YAV25L2TC12E1FX |
| Material | Copper |
| Max Temp | 194 ?F |
| Net Weight | 0 lbs |
| Physical Attribute - Number of Holes | 2 |
| Physical Attribute - Tongue Angle | Straight |
| Physical Attribute - Tongue Type | Standard |
| Plated | Y |
| Plating Material | Electro-Tin |
| Plating Type | Tin |
| Product Series | YAV-L-2TC-FX |
| Rating - KVA | 35 kV |
| Rating - Minimum Voltage | 600 |
| Standards - RoHS Compliance Status | CM |
| Stud Spacing | 1 |
| Temperature Rating | 194 |
| Terminal Material | Copper |
| Terminal Type | Barrel - Standard, Two Hole |
| Tongue Width | 0.83 " |
| UL Listed | Yes |
| Voltage - Maximum | 35000 |
| Volts | 600 V |
| Wire Size | 1/0 AWG |
| Wire Size (AWG) | 1/0 AWG |
| Wire Strip Length | 0.6875 " |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Megadepot | YAV25L2TC12E1FX | 15.75 | 951.3 | 1 | 100 | Burndy | 15.75 @ Qty: 100+ | ||
 | usmegastore.com | YAV25L2TC12E1FX | 15.75 | 951.3 | 1 | 100 | Burndy | 15.75 @ Qty: 100+ | ||
 | Galco | YAV25L2TC12E1FX-BURN | 21.85 | 2185.0 | 100 | 100 | Burndy | 21.85 @ Qty: 100+ |
