mpn:
brand:
manufacturer:
MPN:
Weight:
0.085
Weight:
0.085 LB
Preferred Price:
180.8
Price:
180.8
Min Simple Price:
9.88
Absolute Min Price:
140.29
Min Price:
140.29
Dimensions:
[4.0, 3.0, 3.0]
qty:
1
simpleSku:
NTAxNw:::YAV26L12BOX
sku:
NTAxNw::2Q:YAV26L12BOX@y1
condition:
11
seller:
usmegastore.com
amzMan:
burndy
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Approvals | CSA, UL |
| Certification - CSA Approved, Certification - cULus, Certification - ETL, Certification - UL Recognized | No |
| Conductor - Copper Str Aircraft Size, Conductor - Copper Str Aircraft Size Range | AN 00 |
| Conductor - Copper Str Size, Conductor - Copper Str Size Range, Wire Size, Wire Size (AWG) | 2/0 AWG |
| Connector Type | Terminal |
| Die Index | 44 |
| Dimension - B Length fraction | 3/4 in |
| Dimension - B Length inch | 0.78 in |
| Dimension - Bolt Hole Size inch | 0.66 in |
| Dimension - D inch | 1.15 in |
| Dimension - Hole Size mm | 17 mm |
| Dimension - Length Overall inch | 2.52 in |
| Dimension - N inch | 0.53 in |
| Dimension - Pad Width inch | 0.93 in |
| Dimension - Strip Length inch | 13/16 in |
| Dimension - Stud Size inch | 5/8 in |
| Dimension - Z inch | 0.62 in |
| Family Series | Burndy Terminals, YAV-L Series |
| Feature - Barrel Style | Chamfered |
| Feature - Barrel Type | Standard |
| Gross Weight, Net Weight | 0 lbs |
| Industry Standard(s), Standards - Industry Standards Met | UL467 |
| Insulated | Non-Insulated |
| Item Number, Manufacturer Part Number | YAV26L12BOX |
| Manufacturer | Burndy |
| Material, Terminal Material | Copper |
| Physical Attribute - Number of Holes | 1 |
| Physical Attribute - Tongue Angle | Straight |
| Physical Attribute - Tongue Type, Terminal Type | Ring |
| Plated | Y |
| Plating Material | Electro-Tin |
| Plating Type | Tin |
| Product Series | YAV-L |
| Standards - RoHS Compliance Status | CM |
| Type | Ring Tongue |
| UL Listed | Yes |
| Wire Strip Length | 0.8125 " |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | usmegastore.com | YAV26L12BOX | 9.88 | 63.232 | 1 | 10 | Burndy | 9.88 @ Qty: 10+ | ||
 | Galco | YAV26L12BOX-BURN | 12.68 | 126.8 | 10 | 10 | Burndy | 12.68 @ Qty: 10+ |
