mpn:
brand:
manufacturer:
MPN:
Weight:
0.1
Weight:
0.1 LB
Preferred Price:
31.03
Price:
31.03
Min Simple Price:
14.09
Absolute Min Price:
25.26
Min Price:
25.26
Dimensions:
[60.0, 3.0, 1.0]
qty:
21
simpleSku:
NjQxNw:::YH2C2C
sku:
NjQxNw::GM:YH2C2C@y0
condition:
11
seller:
Specialized Products
amzMan:
burndy
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Approvals | CSA, UL |
| Brand | CRIMPIT |
| Certification - CSA Approved, RoHS Compliant, UL Listed | Yes |
| Certification - cULus, Certification - UL Recognized | No |
| Color, Color Code | Brown |
| Comments | Main 6-2 AWG, Tap1 6-2 AWG, Tap2 14-8 AWG, Tap3 14-8 AWG |
| Conductor - Copper Flex G Run Range, Conductor - Copper Flex H Run Range, Conductor - Copper Flex I Run Range, Conductor - Copper Flex K Run Range, Conductor - Copper Flex M Run Range | 8 AWG-2 AWG |
| Conductor - Copper Flex G Run, Conductor - Copper Flex H Run, Conductor - Copper Flex I Run, Conductor - Copper Flex K Run, Conductor - Copper Flex M Run | 8 AWG; 7 AWG; 6 AWG; 5 AWG; 4 AWG; 3 AWG; 2 AWG |
| Conductor - Copper Flex I Tap, Conductor - Copper Flex K Tap, Conductor - Copper Flex M Tap | 8; 7; 6; 5; 4; 3; 2 |
| Conductor - Copper Solid Run, Conductor - Copper Solid Tap | 6; 5; 4; 3; 2 |
| Connector Type, Terminal Type | H-Tap |
| Country of Origin | US - United States |
| Country of Origin (subject to change) | United States |
| Die Index | C |
| Dimension - Height inch, Dimension - Width inch | 1.25 in |
| Dimension - L Length Overall mm | 19 mm |
| Dimension - Length Overall inch | 0.75 in |
| Dimension - Strip Length inch | 7/8 |
| Dimension - Width fraction | .60 in |
| ECCN | EAR99 |
| Family Series | Burndy Terminals, YH Series |
| Gross Weight | 0.08 lbs |
| Industry Standard(s) | UL467 |
| Insulated | Non-Insulated |
| Item Number, Manufacturer Part Number | YH2C2C |
| Main Conductor Size | 2 to 6 AWG |
| Manufacturer | Burndy |
| Material, Terminal Material, Use With | Copper |
| Max Temp | 194 ?F |
| Net Weight | 0.085 lbs |
| Plated | Y |
| Plating Material | Tin |
| Plating Type | Tin - Electro Plated |
| Product Series | YH |
| Rating - KVA | 35 kV |
| Rating - Minimum Voltage | 600 |
| Standards - RoHS Compliance Status | CM |
| Temperature Rating | 194 |
| Type | Compression Taps |
| UNSPSC | 39121427 |
| UPC Code | 781810013861 |
| Voltage - Maximum | 35000 |
| Volts | 35,000 V |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Specialized Products | 109X419 | 14.09 | 14.09 | 1 | In Stock | 43 | Burndy | 14.09 @ Qty: 1+ | |
 | Zoro | G202438851 | 15.8 | 15.8 | 1 | In Stock | 59 | Burndy | 15.8 @ Qty: 1+ | |
 | usmegastore.com | YH2C2C | 23.17 | 23.17 | 1 | In Stock | Burndy | 23.17 @ Qty: 1+ | ||
 | gordonelectricsupply.com | YH2C2C | 23.98 | 23.98 | 1 | In Stock | BURNDY | 23.98 @ Qty: 1+ | ||
| Graybar | 91006643 | 29.1536 | 29.1536 | 1 | 1 | Burndy | 29.1536 @ Qty: 1+ | |||
| us.rs-online.com | 71496229 | 30.53 | 30.53 | 1 | 5 | BURNDY | 30.53 @ Qty: 1+ | |||
 | Galco | YH2C2C-BURN | 33.22 | 33.22 | 1 | In Stock | Burndy | 0.085 | 33.22 @ Qty: 1+ | |
| kirbyrisk.com | 1928751 | 38.81 | 38.81 | 1 | In Stock | Burndy | 38.81 @ Qty: 1+ |
