- mpn7203P3YZQE
- brandname: C&K
- manufacturername: C&K
C & K COMPONENTS 7203P3YZQE Toggle Switch,STRAIGHT,DPDT,ON-OFF-ON,SOLDER Terminal,PADDLE
- Brand: C&K Components
- PartNumber: 7203P3YZQE
- Model: 7203P3YZQE
- PackageQuantity: 1
- Manufacturer: C&K Components
- Label: C&K Components
Attributes
| Key | Value |
|---|
| Actuator Length | 11.43mm, Non-Illuminated |
| Actuator Material | 40,000 Cycles, Brass, C. |
| Actuator Type | Flat Anti-Rotation, 11.. |
| Application | Used in telecommunicati. |
| Base Product Number | 7203 |
| Body Material | Glass Filled Nylon |
| Body Style | Miniature |
| Bushing Thread | -, 1/4-40 |
| Category | Switches |
| Circuit | DPDT, On-Off-On |
| Contact Form | DPDT |
| Contact Material | Silver |
| Contact Resistance | 10 mOhms |
| Current Rating | 5 A |
| Current Rating (Amps) | Flat Anti-Rotation, 5A . |
| Dielectric Strength | 1000 V |
| Electrical Life | 120 V, 40,000 Cycles |
| Features | Epoxy Sealed Terminals,. |
| Illumination | Non-Illuminated, - |
| Illumination Type, Color | - |
| Illumination Voltage (N. | Solder Lug, - |
| Ingress Protection | Epoxy Sealed Terminals,. |
| Insulation Resistance | 1000000000 Ohms |
| Maximum Operating Tempe. | +85 ?C |
| Mfr | C&K |
| Minimum Operating Tempe. | -30 ?C |
| Mounting Type | DPDT, Panel Mount |
| Number of Poles | 2 |
| Number of Positions | 3 |
| Operating Temperature | -30?C ~ 85?C, Brass, Ch. |
| Operation | On-Off-On |
| Package | Active, Bulk |
| Panel Cutout Dimensions | Circular - 6.35mm Dia, . |
| Part Status | Panel Mount |
| Product Status | Active |
| Series | Bulk, 7000, 7000 Series |
| Switch Function | 5A (AC/DC), On-Off-On |
| Termination | Solder Lugs |
| Termination Style | Solder Lug, Circular - . |
| Type | Toggle |
| Voltage Rating | 250 V |
| Voltage Rating - AC | 120 V, 28 V |
| Voltage Rating - DC | 28 V |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| us.rs-online.com | 70128532 | 13.17 | 1 | 29 | | C&K | | 13.17 @ 2 |
| Newark | 37AH1478 | 17.16 | 100 | 2 | | C&K COMPONENTS | | 17.16 @ 100 |
| Digi-Key | 305080 | 18.048 | 1 | 2 | | C&K | | 18.048 @ 2 |
| AmazonSC | B013ES64QI | 26.22 | 1 | 2 | | C&K Components | | 26.22 @ 2 |
| Hawk Electronics | 7203P3YZQE | 35.0 | 50 | 2 | | C&K | | 35.0 @ 50 |
