mpn:
brand:
manufacturer:
MPN:
Description:
<p><strong> </strong> <strong>, Heat-Shrinkable Tubing 0.25" x 3937.01", Yellow </strong> </p> <p>H2 type heat-shrinkable tubing is used to provide highly legible and resistant identification of cables, pipes, conduits, etc within a minimum space. Halogen free composition provides flame retardancy and low smoke emission characteristics suitable for safety critical applications including closed environments such as tunnels and subways, rail installations, marine and industrial applications. </p>
Attributes
| Key ^ | Value |
|---|---|
| Color | Yellow |
| Diameter pre-shrinkage | 0.25" |
| Halogen Free, Printable on both sides | yes |
| Internal diam. before shrinkin mm | 6.4 |
| Lengthx | 3937.01" |
| Material | Cross-linked polyolefin |
| Max operating temperature range | 221 ?F |
| Maximum outside diameter | 0.23 in. |
| Maximum section | 10 AWG |
| Min operating temperature range | -40 ?F |
| Min shrinkaage ratio temperature | 194 ?F |
| Minimum outside diameter | 0.17 in. |
| Minimum section | 12 AWG |
| Shrinkaage ratio | 2:1 |
| SWcode | 7030 |
