mpn:
brand:
manufacturer:
MPN:
Weight:
9.68
Weight:
9.0 LB
Preferred Price:
352.86
Price:
352.86
Min Simple Price:
199.36
Absolute Min Price:
283.08
Min Price:
283.08
Dimensions:
[19.0, 8.0, 8.0]
qty:
21
simpleSku:
NjIzOQ:::638
sku:
NjIzOQ::UC:638@y0
condition:
11
seller:
cshincorporated.com
amzMan:
a.o. smith
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| 638 is listed in Century's cross reference as a substitute for the following | A.O. Smith 322P497, A.O. Smith DBL4500, A.O. Smith F42D53A01, Ice Cap DE2E132, Ice Cap DE2E188, Ice Cap ELB1271, Universal Electric DE2E132, Universal Electric DE2E7188 |
| Amps | 0.87 |
| Application | Fans and Blowers |
| Bearings, Motor Bearings | Sleeve |
| Body Dia., Motor Diameter | 5" |
| Capacitor | 4MFD @ 370VAC Required |
| Capacitor Required | 2MDV3 |
| Country of Origin (subject to change) | Mexico |
| Duty | Continuous Air Over |
| Duty Cycle | Continuous |
| Enclosure Type | OAO (Open Air Over) |
| Extended Thru-Bolts, Usable @ 200V, Usable @ 208V | No |
| Frame | 42 |
| Full Load Amps | 0.87A |
| HP | 1/10 HP, 1/10 |
| Hz | 60, 60 Hz |
| Ins. Class, Insulation Class | B |
| Item | Motor |
| Length Less Shaft | 3 3/4 in |
| Manufacturers Warranty Length | 1 yr. |
| Max. Ambient Temp. | 40 Degrees C |
| Maximum Ambient Temperature | 40? C |
| Motor Application | OEM Replacement |
| Motor Design | Permanent Split Capacitor |
| Motor Enclosure Design | Open Air-Over |
| Motor Frame Material | Steel |
| Motor Mounting Type | Resilient Base |
| Motor Service Factor, Service Factor (SF) | 1.00 |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | Clockwise Lead End |
| Motor Sub Application | Direct Drive Fan/Blower |
| Motor Thermal Protection | Automatic |
| Mounting | Cradle |
| Mounting Stud Length | Not Applicable |
| Nameplate RPM | 1695 rpm |
| No. of Speeds, Number of Speeds | 3 |
| Number of Shafts, Phase | 1 |
| OEM Replacement Brand | Ice Cap |
| Overall Length | 16.74" |
| Product Type | PSC (Permanent Split Capacitor) |
| Replacement For | DE2E132 |
| Rotation | Double Shafted |
| RPM | 1695 |
| RPM Range | 1601-1700 |
| Shaft Dia. | 1/2" |
| Shaft Diameter | 3/8" |
| Shaft Length | 6-1/2" x 6-1/2", 6-1/2" |
| Ship Weight | 9 lbs. |
| Standards | UL Recognized, CSA Certified |
| Voltage | 115V |
| Voltage Compatibility | 115V AC, 120V AC |
| Volts | 115 |
| Weight | 9 lb |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | cshincorporated.com | U638 | 199.36 | 199.36 | 1 | In Stock | AO Smith / Century | 9.0 | 199.36 @ Qty: 1+ | |
 | Zoro | G2034028 | 212.0 | 212.0 | 1 | In Stock | 26 | Century | 9.0 | 212.0 @ Qty: 1+ |
 | sustainablesupply.com | C2090743 | 216.96 | 216.96 | 1 | In Stock | Century | 15.0 | 216.96 @ Qty: 1+ | |
 | patrickssupply.com | 638 | 220.12 | 220.12 | 1 | In Stock | CENTURY | 220.12 @ Qty: 1+ | ||
 | emotorpro.com | 638 | 232.12 | 232.12 | 1 | In Stock | Century | 9.0 | 232.12 @ Qty: 1+ | |
 | midwestapplianceparts.com | 638-AO-P | 234.46 | 234.46 | 1 | In Stock | AO Smith | 234.46 @ Qty: 1+ |
