Description:
Amps: 2.3/2.2/1.1Bearings: BallDuty Cycle: ContinuousEnclosure Material: Rolled SteelEnclosure Type: TEAO (Totally Enclosed Air Over)Frame: 56HP: 1/2Hz: 60Insulation Class: BManufacturer Model #: 52A109678P1Maximum Ambient Temperature: 40? CMotor Shell Length: 5.72"Mounting: BaseOverall Length: 10.5"Phase: 3Product Typ
Attributes
| Key ^ | Value |
|---|---|
| Amps | 2.3/2.2/1.1 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Enclosure Material | Rolled Steel |
| Enclosure Type | TEAO (Totally Enclosed Air Over) |
| Frame | 56 |
| HP | 1/2 |
| Hz | 60 |
| Insulation Class | B |
| Manufacturer Model # | 52A109678P1 |
| Maximum Ambient Temperature | 40? C |
| Motor Shell Length | 5.72" |
| Mounting | Base |
| Overall Length | 10.5" |
| Phase | 3 |
| Product Type | Capacitor Start/Capacitor Run |
| Rotation | Reversible |
| RPM | 1725 |
| Service Factor | 1.0 |
| Shaft Diameter | 5/8" |
| Shaft Length | 1-7/8" |
| Ship Weight | 20 lbs. |
| Volts | 208, 230, 460 |
