mpn:
brand:
manufacturer:
MPN:
Description:
Product Type: 3 PhaseHP: 2RPM: 3450Volts: 200-230/460Amps: 6/5.5/2.75Hz: 60Phase: 3Frame: 56Enclosure Type: TEFC (Totally Enclosed Fan Cooled)Mounting: RigidMotor Diameter: 6-1/2"Shaft Diameter: 5/8" KeyedShaft Length: 1-7/8"Rotation: ReversibleNumber of Speeds: 1Service Factor (SF): 1.15Bearings: BallThermal Protectio
Attributes
| Key ^ | Value |
|---|---|
| Amps | 6/5.5/2.75 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Frame | 56 |
| H537 is listed in Century's cross reference as a substitute for the following | A.O. Smith 159220, A.O. Smith 327P266, A.O. Smith EB3202, A.O. Smith P56N2T3100, A.O. Smith P56N2TE100, A.O. Smith P56N2TE101, A.O. Smith P56N2UE104, Baldor M3555, Century 159220, Century H537, Dayton 3N445, Dayton 3N564, Leeson 111916, Leland Faraday M22020, Marathon G384, Universal Electric H537 |
| HP | 2 |
| Hz | 60 |
| Insulation Class | B |
| Maximum Ambient Temperature | 40? C |
| Motor Diameter | 6-1/2" |
| Mounting | Rigid |
| Number of Speeds | 1 |
| Phase | 3 |
| Product Type | 3 Phase |
| Rotation | Reversible |
| RPM | 3450 |
| Service Factor (SF) | 1.15 |
| Shaft Diameter | 5/8" Keyed |
| Shaft Length | 1-7/8" |
| Ship Weight | 34 lbs. |
| Thermal Protection | None |
| Volts | 200-230/460 |
