mpn:
brand:
manufacturer:
MPN:
Description:
Product Type: 3 PhaseHP: 3RPM: 3450Volts: 200-230/460Amps: 4.3/9/8.6Hz: 60Phase: 3Frame: 56HZEnclosure Type: ODP (Open Dripproof)Mounting: RigidMotor Diameter: 6-1/2"Shaft Diameter: 7/8" KeyedShaft Length: 2-5/16"Rotation: ReversibleNumber of Speeds: 1Service Factor (SF): 1.15Bearings: BallThermal Protection: Automatic
Attributes
| Key ^ | Value |
|---|---|
| Amps | 4.3/9/8.6 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Enclosure Type | ODP (Open Dripproof) |
| Frame | 56HZ |
| H757 is listed in Century's cross reference as a substitute for the following | A.O. Smith P56P2T8, A.O. Smith P56P2T8B3, A.O. Smith P56P2T8B6, A.O. Smith 182535, A.O. Smith BR3302, A.O. Smith P56P2T8C40, A.O. Smith P56P2T8C41, Baldor M3158, Carrier/BDP 48DA680122, Century 182535, Dayton 2Z267, Universal Electric H757 |
| HP, Phase | 3 |
| Hz | 60 |
| Insulation Class | B |
| Maximum Ambient Temperature | 40? C |
| Motor Diameter | 6-1/2" |
| Mounting | Rigid |
| Number of Speeds | 1 |
| Product Type | 3 Phase |
| Rotation | Reversible |
| RPM | 3450 |
| Service Factor (SF) | 1.15 |
| Shaft Diameter | 7/8" Keyed |
| Shaft Length | 2-5/16" |
| Ship Weight | 35 lbs. |
| Thermal Protection | Automatic |
| Volts | 200-230/460 |
