Description:
Product Type: Capacitor StartHP: 1RPM: 3450Volts: 115/230Amps: 19.2/9.6Hz: 60Phase: 1Frame: 48YEnclosure Type: ODP (Open Dripproof)Mounting: Round FlangeMotor Diameter: 5-5/8"Shaft Diameter: ThreadedRotation: CCW Pump EndNumber of Speeds: 1Service Factor (SF): 1.65Bearings: BallThermal Protection: AutomaticMaximum Ambi
Attributes
| Key | Value |
|---|---|
| Amps | 19.2/9.6 |
| Bearings | Ball |
| Capacitor | Included |
| Duty Cycle | Continuous |
| Enclosure Type | ODP (Open Dripproof) |
| Frame | 48Y |
| HP | 1 |
| Hz | 60 |
| Insulation Class | B |
| Maximum Ambient Temperature | 40? C |
| Motor Diameter | 5-5/8" |
| Mounting | Round Flange |
| Number of Speeds | 1 |
| Phase | 1 |
| Product Type | Capacitor Start |
| R1102 is listed in Century's cross reference as a substitute for the following | A.O. Smith C48L2FA11, A.O. Smith C48L2FB11, A.O. Smith C48L2FC11, A.O. Smith C48L2FC11A1, A.O. Smith C48L2FC11A2, A.O. Smith C48L2FC11A3, A.O. Smith C56L2A2, A.O. Smith C56L2A4, A.O. Smith C56L2B1, A.O. Smith C56L2F1, Sta Rite A200EH, Sta Rite A200FL, Sta Rite J218-599AC |
| Rotation | CCW Pump End |
| RPM | 3450 |
| Service Factor (SF) | 1.65 |
| Shaft Diameter | Threaded |
| Ship Weight | 26 lbs. |
| Thermal Protection | Automatic |
| Volts | 115/230 |
